Harley-Davidson 883 Roadster - 2011 Specifications and Reviews

2011
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2011
ModelHarley-Davidson 883 Roadster

Engine and Transmission Specifications

Exhaust systemChrome, staggered shorty exhaust with dual mufflers
DrivelinePrimary Drive Chain, 57/34 ratio. Final Drive Belt, 68/29 ratio
ClutchMulti-plate with diaphragm spring in oil bath
Transmission type,final driveBelt
Gearbox6-speed
Cooling systemAir
Lubrication systemDry-sump
Fuel controlOHV
Fuel systemInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke76.2 x 96.8 mm (3.0 x 3.8 inches)
Compression8.9:1
Torque70.00 Nm (7.1 kgf-m or 51.6 ft.lbs) @ 3750
Engine detailsAir-cooled Evolution engine. Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters.
Engine typeV2, four-stroke
Capacity:883.32 ccm (53.90 cubic inches)

Brakes, suspension, Frame and wheels

WheelsBlack, 13-Spoke Cast Aluminum
Rear brakes diameter260 mm (10.2 inches)
Rear brakesSingle disc
Front brakes diameter292 mm (11.5 inches)
Front brakesSingle disc. Dual-piston.
Rear tyre dimensions150/80-B16
Front tyre dimensions100/90-19
Rear suspension travel41 mm (1.6 inches)
Rear suspensionCoil-over, preload dual-adjustable
Front suspension travel92 mm (3.6 inches)
Front suspension39 mm fork
Trail145 mm (5.7 inches)
Rake (fork angle)31.0°
Frame typeMild steel, tubular frame; circular sections; cast junctions



Physical measures and capacities

Oil capacity2.80 litres (0.18 quarts)
Fuel capacity12.49 litres (3.30 gallons)
Wheelbase1,519 mm (59.8 inches)
Ground clearance99 mm (3.9 inches)
Overall width820 mm (32.3 inches)
Overall length2,179 mm (85.8 inches)
Overall height1,107 mm (43.6 inches)
Seat height653 mm (25.7 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc256.3 kg (565.0 pounds)
Dry weight248.6 kg (548.0 pounds)

Other specs

Color optionsVivid Black, Sedona Orange
ElectricalSealed lead acid, maintenance-free batery, 12V, 12 amp/hour, 200 cca. 30-amp, permanent magnet, single-phase alternator with solid-state regulator.
Light55-watt low beam, 60-watt high beam
InstrumentsHandlebar-mounted electronic speedometer with odometer, time-of-day clock odometer, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lightsHandlebar-mounted electronic speedometer with odometer, tim
StarterElectric
