Harley-Davidson FLSTC Heritage Softail Classic - 2012 Specifications and Reviews

2 stars Average rating: 2 from 1 votes
.

General information

CategoryCustom / cruiser
Year2012
ModelHarley-Davidson FLSTC Heritage Softail Classic

Engine and Transmission Specifications

Exhaust systemChrome, staggered shorty exhaust with dual mufflers
Greenhouse gases129.9 CO
Fuel consumption5.60 litres/100 km (17.9 km/l or 42.00 mpg)
DrivelinePrimary Drive Chain, 34/46 ratio. Final Drive Belt, 32/66 ratio.
ClutchMulti-plate, wet
Transmission type,final driveBelt
Gearbox6-speed
Cooling systemAir
Lubrication systemPressurized, dry-sump
Fuel systemInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke98.4 x 111.3 mm (3.9 x 4.4 inches)
Compression9.6:1
Torque131.40 Nm (13.4 kgf-m or 96.9 ft.lbs) @ 3000
Engine detailsAir-cooled, Twin Cam 103B
Engine typeV2, four-stroke
Capacity:1687.97 ccm (103.00 cubic inches)



Brakes, suspension, Frame and wheels

WheelsSteel Laced
Rear brakes diameter292 mm (11.5 inches)
Rear brakesSingle disc. 2-piston caliper. Optional ABS.
Front brakes diameter292 mm (11.5 inches)
Front brakesSingle disc. 4-piston caliper. Optional ABS.
Rear tyre dimensions150/80-B16
Front tyre dimensionsMT90-B16
Rear suspension travel91 mm (3.6 inches)
Rear suspensionHidden, horizontal-mounted, coil-over
Front suspension travel109 mm (4.3 inches)
Front suspension41.3 mm telescopic, beer can covers
Trail130 mm (5.1 inches)
Rake (fork angle)31.0°
Frame typeMild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded

Physical measures and capacities

Oil capacity3.30 litres (0.22 quarts)
Fuel capacity18.93 litres (5.00 gallons)
Wheelbase1,638 mm (64.5 inches)
Ground clearance130 mm (5.1 inches)
Overall length2,400 mm (94.5 inches)
Seat height648 mm (25.5 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc345.2 kg (761.0 pounds)
Dry weight331.1 kg (730.0 pounds)

Other specs

CommentsFrench brand.
Wheelbase1,285 mm (50.6 inches)
Overall width685 mm (27.0 inches)
Overall height1,150 mm (45.3 inches)
Power/weight ratio0.0472 HP/kg
Rear tyre3.00-12
Front tyre2.50-12
IgnitionCDI
Torque4.00 Nm (0.4 kgf-m or 3.0 ft.lbs) @ 5500 Revolutions">RPM
Power4.15 Horsepower">HP (3.0 Kilowatt">kW)) @ 8000 Revolutions">RPM
Capacity:49.20 ccm (3.00 cubic inches)
ModelGoes G 55 R Sport
Color optionsVivid Black, Big Blue Pearl, White Hot Pearl, Ember Red Sunglo/Merlot Sunglo, Midnight Pearl/Brilliant Silver Pearl, Tequila Sunrise/H-D Orange
Factory warranty2 years, unlimited mileage.
SeatTwo-piece, two-up Softail seat with removable pillion
ElectricalSealed, maintenance-free battery, 12V, 19-amp/hour, 270 cca
Light55-watt low beam, 60-watt high beam headlamp
InstrumentsTank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
StarterElectric
