Harley-Davidson Tri Glide Ultra Classic - 2013 Specifications and Reviews

2013
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryTouring
Year2013
ModelHarley-Davidson Tri Glide Ultra Classic

Engine and Transmission Specifications

Exhaust systemChrome, 2-1-2 dual exhaust with tapered mufflers
Greenhouse gases143.6 CO
Fuel consumption6.19 litres/100 km (16.2 km/l or 38.00 mpg)
DrivelineChain, 34/46 ratio primary drive
ClutchMulti-plate with diaphragm spring in oil bath
Transmission type,final driveBelt
Gearbox6-speed
Cooling systemAir
Fuel systemInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke98.4 x 111.3 mm (3.9 x 4.4 inches)
Compression9.6:1
Torque135.60 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3250
Engine detailsAir-cooled, Twin Cam 103™
Engine typeV2, four-stroke
Capacity:1687.97 ccm (103.00 cubic inches)



Brakes, suspension, Frame and wheels

WheelsBlack, 7-spoke Cast Aluminum. Two rear wheels.
Rear brakesSingle disc
Front brakesSingle disc
Rear tyre dimensions205/65-15
Front tyre dimensions130/60-21
Trail100 mm (3.9 inches)
Rake (fork angle)26.0°

Physical measures and capacities

Oil capacity3.80 litres (0.25 quarts)
Fuel capacity22.71 litres (6.00 gallons)
Wheelbase1,692 mm (66.6 inches)
Ground clearance119 mm (4.7 inches)
Overall length2,687 mm (105.8 inches)
Seat height688 mm (27.1 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc0.5 kg (1.2 pounds)

Other specs

Wheelbase1,800 mm (70.9 inches)
Overall width1,600 mm (63.0 inches)
Overall height1,400 mm (55.1 inches)
Dry weight535.2 kg (1,180.0 pounds)
Rear SuspensionIndependent coil springs and hydraulic dampers
Front SuspensionIndependent coil springs and hydraulic dampers
Fuel controlDouble Overhead Cams/Twin Cam (DOHC)
Valves per cylinder4
Top speed45.0 km/h (28.0 mph)
Capacity:1300.00 ccm (79.33 cubic inches)
ModelGibbs Quadski
CommentsTrike. Windshield. CVO is HD´s Custom Vehicle Operation.
Color optionsAnniversary Vintage Bronze/Anniversary Vintage Black, Midnight Pearl/Brilliant Silver Pearl, Big Blue Pearl/Vivid Black, Ember Red Sunglo, Vivid Black
Carrying capacityTrunk and top box
LightHigh Beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system (optional), 6 speed, low fuel warning, reverse enabled
InstrumentsFairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light; cruise control indicator light Tachometer with fuel, voltage, oil pressure and ambient air temperature gauges
StarterElectric
