Harley-Davidson XL1200X Springer Forty-Eight - 2012 Specifications and Reviews

2012
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2012
ModelHarley-Davidson XL1200X Springer Forty-Eight

Engine and Transmission Specifications

Exhaust systemChrome, staggered shorty exhaust with dual slash-cut mufflers
Greenhouse gases113.7 CO
Fuel consumption4.90 litres/100 km (20.4 km/l or 48.00 mpg)
DrivelinePrimary drive chain, 57/38 ratio. Final Drive Belt, 68/29 ratio
ClutchMulti-plate with diaphragm spring in oil bath
Transmission type,final driveBelt
Gearbox5-speed
Cooling systemAir
Lubrication systemDry-sump
Fuel systemInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke88.9 x 96.8 mm (3.5 x 3.8 inches)
Compression9.7:1
Torque107.12 Nm (10.9 kgf-m or 79.0 ft.lbs) @ 4000
Engine detailsBlacked out rubber-mounted Evolution 1200 cc V-Twin engine with polished covers
Engine typeV2, four-stroke
Capacity:1201.25 ccm (73.30 cubic inches)



Brakes, suspension, Frame and wheels

WheelsBlack, Laced Steel
Rear brakes diameter260 mm (10.2 inches)
Rear brakesSingle disc. Single-piston
Front brakes diameter292 mm (11.5 inches)
Front brakesSingle disc. Dual-piston
Rear tyre dimensions150/80-B16
Front tyre dimensions130/90-B16
Rear suspension travel41 mm (1.6 inches)
Rear suspensionMild steel, rectangular tube section, stamped junctions, MIG welded swing-arm. Coil-over; preload dual-adjustable shocks.
Front suspension travel92 mm (3.6 inches)
Front suspension39 mm
Trail107 mm (4.2 inches)
Rake (fork angle)30.0°
Frame typeMild steel, tubular frame; circular sections; cast junctions

Physical measures and capacities

Oil capacity2.60 litres (0.17 quarts)
Fuel capacity7.95 litres (2.10 gallons)
Wheelbase1,519 mm (59.8 inches)
Ground clearance99 mm (3.9 inches)
Overall length2,250 mm (88.6 inches)
Seat height660 mm (26.0 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc257.2 kg (567.0 pounds)
Dry weight247.2 kg (545.0 pounds)



Other specs

CommentsFrench brand.
StarterElectric & kick
Wheelbase1,285 mm (50.6 inches)
Overall width685 mm (27.0 inches)
Overall height1,150 mm (45.3 inches)
Power/weight ratio0.0472 HP/kg
Rear tyre3.00-12
Front tyre2.50-12
IgnitionCDI
Torque4.00 Nm (0.4 kgf-m or 3.0 ft.lbs) @ 5500 Revolutions">RPM
Power4.15 Horsepower">HP (3.0 Kilowatt">kW)) @ 8000 Revolutions">RPM
Capacity:49.20 ccm (3.00 cubic inches)
ModelGoes G 55 R Sport
Color optionsVivid Black, Big Blue Pearl, Chrome Yellow, H-D Orange
Factory warranty24 months, unlimited mileage.
SeatOne-piece, Sportster classic solo seat
ElectricalSealed lead acid battery, maintenance-free, 12V, 12 amp/hour, 200 cca.
Instruments4-inch Speedometer mounted low and integrated into handlebar clamp; electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, LED indicator lights
