Kawasaki Vulcan 1500 Classic - 2008 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2008
ModelKawasaki Vulcan 1500 Classic

Engine and Transmission Specifications

Transmission typefinal driveShaft drive (cardan)
Gearbox5-speed
Cooling systemAir
StarterElectric
IgnitionTCBI with Digital Advance
Fuel controlOHV
Valves per cylinder4
Fuel systemInjection. 32 degrees / 6.5 in.
Bore x stroke102.0 x 90.0 mm (4.0 x 3.5 inches)
Compression9.0:1
Torque114.71
Stroke4
Engine typeV2
Capacity:1470.00 ccm (89.70 cubic inches)



Physical measures and capacities

Wheelbase1,666 mm (65.6 inches)
Overall width996 mm (39.2 inches)
Overall length2,504 mm (98.6 inches)
Overall height1,140 mm (44.9 inches)
Seat height701 mm (27.6 inches) If adjustable, lowest setting.
Dry weight298.9 kg (659.0 pounds)

Kawasaki Vulcan 1500 Classic dimensions and frame

Rear brakes diameter270 mm (10.6 inches)
Rear brakesSingle disc
Front brakes diameter300 mm (11.8 inches)
Front brakesSingle disc
Rear tyre dimensions150/80-16
Front tyre dimensions130/90-16
Rear suspensionTwin Shocks, with five-way adjustable preload / 3.4 in.
Front suspension41mm hydraulic telescopic fork / 5.9 in.
Trail165 mm (6.5 inches)
Rake (fork angle)32.0°
Frame typeHigh-tensile steel, double cradle

Speed and acceleration

Color optionsEbony, Two Tone: Candy Cardinal Red / Pearl Crystal White
Fuel capacity18.92 litres (5.00 gallons)
