Kawasaki Vulcan 1600 Classic - 2007 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2007
ModelKawasaki Vulcan 1600 Classic

Engine and Transmission Specifications

Transmission typefinal driveShaft drive (cardan)
Gearbox5-speed
Cooling systemLiquid
StarterElectric
IgnitionTCBI with digital advance
Fuel controlSOHC
Valves per cylinder4
Fuel systemInjection
Bore x stroke102.0 x 95.0 mm (4.0 x 3.7 inches)
Compression9.0:1
Stroke4
Engine typeV2
Capacity:1552.00 ccm (94.70 cubic inches)

Physical measures and capacities

Wheelbase1,679 mm (66.1 inches)
Ground clearance130 mm (5.1 inches)
Overall width1,039 mm (40.9 inches)
Overall length2,504 mm (98.6 inches)
Overall height1,130 mm (44.5 inches)
Seat height696 mm (27.4 inches) If adjustable, lowest setting.
Dry weight306.2 kg (675.0 pounds)



Kawasaki Vulcan 1600 Classic dimensions and frame

Rear brakesSingle disc
Front brakesDouble disc
Rear tyre dimensions170/70-x16
Front tyre dimensions130/90-x16
Rear suspensionDual air-assisted shocks / 3.7 in.
Front suspension41mm hydraulic fork / 5.9 in.
Trail168 mm (6.6 inches)
Rake (fork angle)32.0°
Frame typeHigh-tensile steel, double cradle



Speed and acceleration

Color optionsEbony, Two-Tone Candy Cardinal Red / Metallic Phantom Silver
Fuel capacity20.06 litres (5.30 gallons)
