Kawasaki Vulcan 900 Classic - 2009 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2009
ModelKawasaki Vulcan 900 Classic

Engine and Transmission Specifications

Transmission typefinal driveBelt
Gearbox5-speed
Cooling systemLiquid
StarterElectric
IgnitionTCBI with Electronic Advance
Fuel controlSOHC
Fuel systemInjection
Bore x stroke88.0 x 74.2 mm (3.5 x 2.9 inches)
Compression9.5:1
Torque78.91
Stroke4
Engine typeV2
Capacity:903.00 ccm (55.10 cubic inches)

Physical measures and capacities

Wheelbase1,646 mm (64.8 inches)
Overall width1,006 mm (39.6 inches)
Overall length2,464 mm (97.0 inches)
Overall height1,064 mm (41.9 inches)
Seat height681 mm (26.8 inches) If adjustable, lowest setting.
Dry weight281.0 kg (619.6 pounds)



Kawasaki Vulcan 900 Classic dimensions and frame

Rear brakes diameter272 mm (10.7 inches)
Rear brakesSingle disc
Front brakes diameter272 mm (10.7 inches)
Front brakesSingle disc
Rear tyre dimensions180/70-15
Front tyre dimensions130/90-16
Rear suspensionUni-Track® swingarm / 4.1 in.
Front suspension41mm hydraulic telescopic fork / 5.9 in.
Trail160 mm (6.3 inches)
Rake (fork angle)32.0°
Frame typeDouble-cradle, steel

Speed and acceleration

Color optionsMetallic Diablo Black, Candy Plasma Blue, Candy Diamond Red
Fuel capacity20.06 litres (5.30 gallons)
