Moto Morini Corsaro Avio (2010)

Add/Upload more pictures of this motorcycle   2010 Moto Morini Corsaro Avio specifications
General information
Model:	Moto Morini Corsaro Avio
Year:	2010
Category:	Naked bike
Engine and transmission
Displacement:	1187.00 ccm (72.43 cubic inches)
Engine type:	V2, four-stroke
Power:	120.00
Torque:	102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700
Compression:	12.5:1
Bore x stroke:	107.0 x 66.0 mm (4.2 x 2.6 inches)
Fuel system:	Injection. Magneti Marelli
Fuel control:	DOHC
Ignition:	I.A.W.
Cooling system:	Liquid
Gearbox:	6-speed
Transmission type,final drive:	Chain
Clutch:	Wet, multiple-plate
Exhaust system:	Double silencer, 3-way catalytic converter and oxygen sensor. Euro 3.
Brakes, suspension, Frame and wheels
Frame type:	Verlicchi high-strength steel tube trellis
Rake (fork angle):	24.5°
Trail:	103 mm (4.1 inches)
Front suspension:	Marzocchi upside-down fully adjustable fork with 50 mm legs
Front suspension travel:	129 mm (5.1 inches)
Rear suspension:	With progressive motion and single Sachs shock absorber adjustable in extension, compression and spring pre-charge
Rear suspension travel:	130 mm (5.1 inches)
Front tyre dimensions:	120/70-ZR17
Rear tyre dimensions:	180/55-ZR17
Front brakes:	Double disc. Bremo, 4-piston
Front brakes diameter:	320 mm (12.6 inches)
Rear brakes:	Single disc. Bremo
Rear brakes diameter:	220 mm (8.7 inches)
Physical measures and capacities
Dry weight:	198.0 kg (436.5 pounds)
Power/weight ratio:	0.6061 HP/kg
Seat height:	830 mm (32.7 inches) If adjustable, lowest setting.
Overall length:	2,070 mm (81.5 inches)
Overall width:	810 mm (31.9 inches)
Ground clearance:	140 mm (5.5 inches)
Fuel capacity:	18.00 litres (4.76 gallons)
Reserve fuel capacity:	4.00 litres (1.06 gallons)
Other specs
Color options:	Silver/blue, black/red
