Suzuki Boulevard C50T Classic - 2012 Specifications and Reviews

2012
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2012
ModelSuzuki Boulevard C50T Classic



Engine and Transmission Specifications

Exhaust systemChromed and staggered dual exhaust
Emission detailsDual spark plugs on each cylinder for better combustion and lower emissions
Driveline5-speed constant mesh
ClutchHydraulic clutch
Transmission type,final driveShaft drive (cardan)
Gearbox5-speed
Cooling systemLiquid
Lubrication systemWet sump
IgnitionElectronic
Fuel controlOHC
Fuel systemInjection
Valves per cylinder4
Bore x stroke83.0 x 74.4 mm (3.3 x 2.9 inches)
Compression9.4:1
Engine typeV2, four-stroke
Capacity:805.00 ccm (49.12 cubic inches)



Brakes, suspension, Frame and wheels

WheelsTraditional spoke wheels. White-wall tires
Rear brakes diameter180 mm (7.1 inches)
Rear brakesExpanding brake (drum brake)
Front brakes diameter300 mm (11.8 inches)
Front brakesSingle disc
Rear tyre dimensions170/80-15
Front tyre dimensions130/90-16
Rear suspensionLink type, coil spring, oil damped
Front suspensionTelescopic forks with polished aluminum sliders and polished stainless steel stanchion-tube covers
Frame typeCradle-type steel

Physical measures and capacities

Fuel capacity15.50 litres (4.10 gallons)
Wheelbase1,655 mm (65.2 inches)
Ground clearance140 mm (5.5 inches)
Overall length2,500 mm (98.4 inches)
Seat height700 mm (27.6 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc292.1 kg (644.0 pounds)

Other specs

CommentsItalian brand.
Factory warranty3 years
InstrumentsElectronic/analogical rev counter and speedometer with multifunctional LCD display
StarterElectric
Reserve fuel capacity4.50 litres (1.19 gallons)
Wheelbase1,470 mm (57.9 inches)
Overall width865 mm (34.1 inches)
Power/weight ratio0.5909 HP/kg
Dry weight198.0 kg (436.5 pounds)
Rear tyre180/55-R17
Front tyre120/70-R17
Rear wheel travel150 mm (5.9 inches)
Rear SuspensionOval steel tube swin arm. Single lateral shock absorber with fully adjustable pibby tank
Front wheel travel150 mm (5.9 inches)
Front SuspensionMarzocchi upside-down fork
Trail100 mm (3.9 inches)
Rake (fork angle)24.5°
Valves per cylinder4
Bore x Stroke107.0 x 66.0 mm (4.2 x 2.6 inches)
Torque102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700 Revolutions">RPM
Power117.00 Horsepower">HP (85.4 Kilowatt">kW)) @ 8500 Revolutions">RPM
Engine details87 degree V-twin
Capacity:1187.00 ccm (72.43 cubic inches)
ModelMoto Morini 9 1-2
Color optionsBlack/Gray, Blue/White
SeatStudded seats, plus matching touring-style backrest with unique pivoting backrest pad for increased passenger comfort
