Suzuki SV 650 S - 2006 Specifications and Reviews

5 stars Average rating: 5 from 1 votes
.

General information

CategoryNaked bike
Year2006
ModelSuzuki SV 650 S

Engine and Transmission Specifications

ClutchWet multiple plate coil springs
Transmission typefinal driveChain
Gearbox6-speed
Cooling systemLiquid
Lubrication systemWet Sump
IgnitionDigital/Transistorized
Fuel controlDOHC
Fuel systemInjection. Fuel Injection
Bore x stroke81.0 x 62.6 mm (3.2 x 2.5 inches)
Compression11.5:1
Stroke4
Engine typeV2
Capacity:645.00 ccm (39.36 cubic inches)

Physical measures and capacities

Wheelbase1,430 mm (56.3 inches)
Ground clearance155 mm (6.1 inches)
Overall width730 mm (28.7 inches)
Overall length2,080 mm (81.9 inches)
Overall height1,170 mm (46.1 inches)
Seat height800 mm (31.5 inches) If adjustable, lowest setting.
Dry weight169.0 kg (372.6 pounds)



Suzuki SV 650 S dimensions and frame

Rear brakesSingle disc
Front brakesDouble disc
Rear tyre dimensions160/60-ZR17
Front tyre dimensions120/60-ZR17
Rear suspensionLink-type, 7-way adjustable spring preload
Front suspensionTelescopic, coil spring, oil damped, fully adjustable preload

Speed and acceleration

Color optionsBlue, Red
Fuel capacity17.00 litres (4.49 gallons)
