Yamaha Royal Star Tour Deluxe - 2006 Specifications and Reviews

5 stars Average rating: 5 from 1 votes
.

General information

CategoryTouring
Year2006
ModelYamaha Royal Star Tour Deluxe

Engine and Transmission Specifications

Transmission type,final driveShaft drive (cardan)
Gearbox5-speed
Cooling systemLiquid
IgnitionDigital TCI
Fuel controlDOHC
Fuel systemCarburettor. 32mm Mikuni Constant-Velocity (4)
Bore x stroke79.0 x 66.0 mm (3.1 x 2.6 inches)
Compression10.0:1
Engine typeV4, four-stroke
Capacity:1294.00 ccm (78.96 cubic inches)



Brakes, suspension, Frame and wheels

Rear brakes diameter320 mm (12.6 inches)
Rear brakesSingle disc
Front brakes diameter298 mm (11.7 inches)
Front brakesDouble disc
Rear tyre dimensions150/90-15
Front tyre dimensions150/80-16
Rear suspension travel104 mm (4.1 inches)
Rear suspensionSingle shock, link-type w/air assist
Front suspension travel142 mm (5.6 inches)
Front suspensionTelescopic fork w/air assist

Physical measures and capacities

Fuel capacity20.06 litres (5.30 gallons)
Wheelbase1,715 mm (67.5 inches)
Overall width1,011 mm (39.8 inches)
Overall length2,504 mm (98.6 inches)
Overall height1,524 mm (60.0 inches)
Seat height739 mm (29.1 inches) If adjustable, lowest setting.
Dry weight357.0 kg (787.0 pounds)

Other specs

Color optionsPerl white
