Yamaha XVZ13TFL MM Limited (2000)

Add/Upload more pictures of this motorcycle   2000 Yamaha XVZ13TFL MM Limited specifications
General information
Model:	Yamaha XVZ13TFL MM Limited
Year:	2000
Category:	Touring
Engine and transmission
Displacement:	1294.00 ccm (78.96 cubic inches)
Engine type:	V4, four-stroke
Power:	98.00
Top speed:	193.1 km/h (120.0 mph)
Compression:	10.0:1
Bore x stroke:	79.0 x 66.0 mm (3.1 x 2.6 inches)
Valves per cylinder:	4
Fuel system:	Carburettor. Mikuni 32mm /4
Fuel control:	DOHC
Ignition:	Digital TCI
Lubrication system:	Wet Sump
Cooling system:	Liquid
Gearbox:	5-speed
Transmission type,final drive:	Shaft drive (cardan)
Clutch:	Wet, multiple-disc
Fuel consumption:	5.88 litres/100 km (17.0 km/l or 40.00 mpg)
Greenhouse gases:	136.4 CO
Exhaust system:	4 into 2
Brakes, suspension, Frame and wheels
Frame type:	Double Cradle with solid mounted engine used as frame member.
Rake (fork angle):	29.1°
Trail:	152 mm (6.0 inches)
Front suspension:	Air adjustable 0 to 7.1psi
Front suspension travel:	140 mm (5.5 inches)
Rear suspension:	Monoshock, air adjustable 0 to 57psi
Rear suspension travel:	105 mm (4.1 inches)
Front tyre dimensions:	150/80-16
Rear tyre dimensions:	150/90-15
Front brakes:	Double disc. 2 Piston Calipers
Front brakes diameter:	298 mm (11.7 inches)
Rear brakes:	Single disc. 4 Piston Caliper
Rear brakes diameter:	320 mm (12.6 inches)
Physical measures and capacities
Dry weight:	366.0 kg (806.9 pounds)
Weight incl. oil, gas, etc:	394.0 kg (868.6 pounds)
Power/weight ratio:	0.2678 HP/kg
Seat height:	750 mm (29.5 inches) If adjustable, lowest setting.
Overall height:	1,565 mm (61.6 inches)
Overall length:	2,655 mm (104.5 inches)
Overall width:	900 mm (35.4 inches)
Ground clearance:	155 mm (6.1 inches)
Wheelbase:	1,705 mm (67.1 inches)
Fuel capacity:	22.50 litres (5.94 gallons)
Reserve fuel capacity:	3.50 litres (0.92 gallons)
Other specs
Starter:	Electric
Color options:	Pearl White / Ivory two-tone with tan seats
