Aprilia RSV4 1100 - 2024 Specifications and Reviews

2024
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryEnduro / offroad
Year2024
Model nameAprilia RX 125

Engine and Transmission Specifications

Emission detailsEuro 5
Greenhouse gases60.3 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption2.60 litres/100 km (38.5 km/l or 90.47 mpg)
DrivelinePrimary drive: Gearbox: 63/19 (3.31). Final drive: Chain: 17/40 (2.35).
ClutchMulti-plate in oil bath.
Transmission typeChain (final drive)
Gearbox6-speed
Cooling systemLiquid
Lubrication systemWet sump
IgnitionECU Electronics Magneti Marelli MIUG4 ø 32 mm
Fuel controlDouble Overhead Cams/Twin Cam (DOHC)
Fuel systemInjection
Valves per cylinder4
Bore x stroke58.0 x 47.0 mm (2.3 x 1.9 inches)
Compression12.6:1
Torque11.2 Nm (1.1 kgf-m or 8.3 ft.lbs) @ 8000 RPM
Power15.0 HP (10.9 kW)) @ 10000 RPM
Engine typeSingle cylinder, four-stroke
Capacity:124.2 ccm (7.58 cubic inches)

Brakes, suspension, Frame and wheels

WheelsAluminium spoked wheel.
Rear brakesSingle disc. Floating calliper
Diameter260 mm (10.2 inches)
Front brakesSingle disc. Floating calliper. Front wheel only ABS.
Rear tire120/80-18
Front tire90/90-21
Rear wheel travel210 mm (8.3 inches)
Rear suspensionSteel swingarm, monoshock with progressive link system
Front wheel travel240 mm (9.4 inches)
Front suspensionØ 41 mm telescopic upside down fork
Frame typeTwin-tube, steel



Physical measures and capacities

Fuel capacity7.00 litres (1.85 US gallons)
Wheelbase1430 mm (56.3 inches)
Overall width820 mm (32.3 inches)
Overall length2145 mm (84.4 inches)
Overall height1140 mm (44.9 inches)
Seat height905 mm (35.6 inches) If adjustable, lowest setting.
Power/weight ratio0.1210 HP/kg
Weight incl. oil, gas, etc134.0 kg (295.4 pounds)
Dry weight124.0 kg (273.4 pounds)

Other specs

StarterElectric
Color optionsBlack Spider, White Wonder
