Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
Type | Sport |
Year model | 2024 |
Model | BMW G 310 R |
Engine and Transmission Specifications |
Exhaust system | Stainless steel |
Emission details | Closed-loop 3-way catalytic converter, emission standard EU-4 |
Greenhouse gases | 77.3 CO2 g/km. (CO2 - Carbon dioxide emission) |
Fuel consumption | 3.33 litres/100 km (30.0 km/l or 70.64 mpg) |
Driveline | X-ring chain with shock absorption in the real wheel hub |
Clutch | Multi-disc oil bath (anti-hopping) with self-reinforcement |
Transmission type | Chain (final drive) |
Gearbox | 6-speed |
Cooling system | Liquid |
Lubrication system | Wet sump |
Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
Fuel system | Injection |
Valves per cylinder | 4 |
Bore x stroke | 80.0 x 62.1 mm (3.1 x 2.4 inches) |
Compression | 10.9:1 |
Top speed | 143.0 km/h (88.9 mph) |
Torque | 28.0 Nm (2.9 kgf-m or 20.7 ft.lbs) @ 7500 RPM |
Effect | 34.0 HP (24.8 kW)) @ 9500 RPM |
Type of engine | Single cylinder, four-stroke |
Capacity: | 313.0 ccm (19.10 cubic inches) |
|
Brakes, suspension, Frame and wheels |
Rear brakes | Single disc. Single-piston floating caliper. ABS. |
Diameter | 300 mm (11.8 inches) |
Front brakes | Single disc. 4-piston fixed caliper, radially bolted. ABS. |
Rear tire | 150/60-R17 |
Front tire | 110/70-R17 |
Rear wheel travel | 132 mm (5.2 inches) |
Rear suspension | Cast aluminum dual swing arm, central spring strut, spring pre-load adjustable |
Front wheel travel | 140 mm (5.5 inches) |
Front suspension | Inverted telescopic fork, Ø 41mm |
Trail | 114 mm (4.5 inches) |
Rake (fork angle) | 25.1° |
Frame type | Tubular space |
Physical measures and capacities |
Oil capacity | 1.70 litres (1.8 US quarts) |
Reserve fuel capacity | 1.00 litres (0.26 US gallons) |
Fuel capacity | 10.98 litres (2.90 US gallons) |
Wheelbase | 1380 mm (54.3 inches) |
Overall width | 849 mm (33.4 inches) |
Overall length | 2005 mm (78.9 inches) |
Overall height | 1080 mm (42.5 inches) |
Seat height | 785 mm (30.9 inches) If adjustable, lowest setting. |
Power/weight ratio | 0.2152 HP/kg |
Weight incl. oil, gas, etc | 164.2 kg (362.0 pounds) |
Dry weight | 158.0 kg (348.3 pounds) |
|
Other specs |
Comments | Ride by wire. |
Factory warranty | 3-years or 36,000 miles warranty |
Light | LED headlight, tail light and LED indicators |
Electrical | 12 V / 8 Ah battery |
Starter | Electric |
Color options | Racing Red, Cosmic Black, Polar White/Racing Blue Metallic |
Maintenance and service data |
Fork tube size | 41 mm (1.6 inches) |
Tire pressure rear | 33 PSI (2.3 Bar or 230 kPa) |
Tire pressure front | 32 PSI (2.2 Bar or 220 kPa) |
Sprockets | 16/40 (front/rear) |
Idle speed | 1600 +/- 100 RPM |
Spark plugs | NGK LMAR9D-J |
Brake fluid | DOT4 |
Update specs | SAE 15W-50 |
