2017BMW R 1200 GS Adventure

42 fields on record

The 2017 BMW R 1200 GS Adventure is a capable adventure tourer designed for riders seeking long-distance touring with genuine off-road capability. Known for its robust boxer engine, comprehensive technology suite, and impressive ground clearance, it excels on both paved highways and unprepared terrain. Its comfortable ergonomics, excellent fuel range, and proven reliability make it ideal for exploratory journeys across diverse landscapes.

Capacity: 1170.0 ccm
Engine: Boxer twin, four-stroke
Gearbox: 6-speed
Dry weight: 229.1 kg
Seat height: 890 mm
Power: 125.0 HP (91.2 kW) @ 7750 RPM

⇄ Compare with another bike All model years

What’s new for the 2017 BMW R 1200 GS Adventure

vs the 2016

Spec	2016	2017
Engine capacity	—	1170.0 ccm (71.40 cubic inches)
Power	125.00 HP (91.2 kW) @ 7750 RPM	125.0 HP (91.2 kW) @ 7750 RPM
Torque	125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 RPM	125.0 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 RPM
Top speed	—	201.2 km/h (125.0 mph)
Weight	229.1 kg (505.0 pounds)	229.1 kg (505.1 pounds)
Fuel capacity	30.00 litres (7.93 gallons)	30.00 litres (7.93 US gallons)
Front suspension	BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut	BMW Motorrad Telelever, front, stanchion diameter 37 mm
Rear suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel	BMW Motrrad EVO Paralever, rear
Front brakes	Double disc. ABS. Floating discs. Four-piston calipers.	Double disc. ABS. Four-piston calipers.
Rear brakes	Single disc. ABS. Floating disc. Two-piston calipers.	Single disc. ABS
Wheelbase	1,510 mm (59.4 inches)	1510 mm (59.4 inches)
Cooling	Oil & air	Liquid

Other years 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail82%

Cornering68%

City riding50%

Daily riding70%

Touring97%

Two-up88%

Track35%

Best for: Built for long-distance, go-anywhere adventure touring across highways, gravel, and rugged backroads with heavy luggage.
Built for: A capable, torquey, and rugged globe-trotter that rewards patience with unmatched versatility and long-haul comfort.
Not ideal for: Not ideal for shorter or less experienced riders seeking a light, nimble machine for tight city streets or track days.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 890mm, a rider of 175cm with a 79cm (estimated) inseam will not reach the ground comfortably on the 2017 BMW R 1200 GS Adventure, with a moderate knee angle of around 100 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 821-900 mm — Long Legs →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1170.0 ccm
Power: 125.0 HP (91.2 kW) @ 7750 RPM
CO2 Emissions: -4 CO2 g/km
Torque: 125.0 Nm (12.7 kgf-m) @ 6500 RPM
Engine type: Boxer twin, four-stroke
Power/weight ratio: 0.5456 HP/kg
Bore x stroke: 101.0 x 73.0 mm
Compression: 12.5:1
Cooling system: Liquid
Fuel system: Injection
Starting: Electric
Valves per cylinder: 4

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Shaft
Clutch: Wet eight-disc clutch with anti-hopping function, hydraulically operated

Performance

Top speed: 201.2 km/h (125.0 mph)

Dimensions & weight

Wheelbase: 1510 mm
Overall length: 2255 mm
Overall width: 980 mm
Overall height: 1450 mm
Seat height: 890 mm
Dry weight: 229.1 kg
Wet weight: 263.0 kg
Fuel capacity: 30.00 litres
Reserve fuel capacity: 4.00 litres
Ground clearance: Not on record - add it

Chassis & suspension

Frame: Two-section frame, front- and bolted on rear frame, load-bearing engine
Front suspension: BMW Motorrad Telelever, front, stanchion diameter 37 mm
Rear suspension: BMW Motrrad EVO Paralever, rear
Front wheel travel: 210 mm
Rear wheel travel: 220 mm
Rake (fork angle): 24.5°
Trail: 93 mm

Brakes & wheels

Front brakes: Double disc. ABS. Four-piston calipers.
Front brakes diameter: 305 mm
Rear brakes: Single disc. ABS
Rear brakes diameter: 276 mm
Front tyre: 120/70-R19
Rear tyre: 170/60-R17

Other

Color options: Light White, Racing Red Matt
Comments: Windscreen. Switchable ABS.

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2006	2009	2013	2016	2017	2019
Capacity	1170.00 ccm (71.39 cubic inches)	1170.00 ccm (71.39 cubic inches)	1170.00 ccm (71.39 cubic inches)	—	—	1170.0 ccm (71.39 cubic inches)
Dry weight	223.0 kg (491.6 pounds)	223.0 kg (491.6 pounds)	229.1 kg (505.0 pounds)	229.1 kg (505.0 pounds)	229.1 kg (505.0 pounds)	229.1 kg (505.0 pounds)
Seat height	910 mm (35.8 inches)	910 mm (35.8 inches)	889 mm (35.0 inches)	890 mm (35.0 inches)	890 mm (35.0 inches)	890 mm (35.0 inches)
Fuel capacity	33.00 litres (8.72 gallons)	33.00 litres (8.72 gallons)	32.93 litres (8.70 gallons)	30.00 litres (7.93 gallons)	30.00 litres (7.93 gallons)	30.00 litres (7.93 US gallons)
Color options	—	Magma red, Magnesium metallic matt	Red, grey	Light White, Ocean Blue metallic Matte, Racing Red Matte	Light White, Racing Red Matt	Racing Red, Light White/Cordoba Blue, Black Storm Metallic/Dark Slate Metallic Matte/Achat Grey
