Benelli TNT 1130 Titanium - 2011 Specifications and Reviews

2011
5 stars Average rating: 5 from 3 votes
.

General information

CategoryNaked bike
Year2011
ModelBenelli TNT 1130 Titanium



Engine and Transmission Specifications

DrivelineStraight toothed primary gear, chain final
ClutchDry clutch
Transmission type,final driveChain
Gearbox6-speed
Cooling systemLiquid
Lubrication systemWet sump
Fuel controlDOHC
Fuel systemInjection
Valves per cylinder4
Bore x stroke88.0 x 62.0 mm (3.5 x 2.4 inches)
Torque122.00 Nm (12.4 kgf-m or 90.0 ft.lbs) @ 6750
Power140.81
Engine detailsCylinders tilted forward 15 degrees. Anti-vibration countershafts
Engine typeIn-line three, four-stroke
Capacity:1131.00 ccm (69.01 cubic inches)



Brakes, suspension, Frame and wheels

WheelsMarchesini forged aluminium
Rear brakes diameter220 mm (8.7 inches)
Rear brakesSingle disc. Bremo
Front brakes diameter320 mm (12.6 inches)
Front brakesSingle disc. Bremo, floating disk
Rear tyre dimensions180/55-;17
Front tyre dimensions120/70-;17
Rear suspension travel120 mm (4.7 inches)
Rear suspensionASD steel tube trellis swingarm with totally adjustable shock absorber
Front suspension travel120 mm (4.7 inches)
Front suspensionMarzocchi upside down fork totally adjustable 50 mm
Trail95 mm (3.7 inches)
Rake (fork angle)24.0°
Frame typeDecomposable, front ASD steel trellis, rear alluminium alloy casting

Physical measures and capacities

Reserve fuel capacity4.00 litres (1.06 gallons)
Fuel capacity17.00 litres (4.49 gallons)
Wheelbase1,419 mm (55.9 inches)
Overall width790 mm (31.1 inches)
Overall length2,100 mm (82.7 inches)
Seat height780 mm (30.7 inches) If adjustable, lowest setting.
Power/weight ratio0.7296 HP/kg
Dry weight193.0 kg (425.5 pounds)

Other specs

CommentsPower Steering
Carrying capacityFront Rack Capacity 100 lbs / 45.4 kg. Rear Rack Capacity 50 lbs / 22.7 kg. Towing Capacity 1,050 lbs / 476.3 kg
Wheelbase1,473 mm (58.0 inches)
Ground clearance1,278 mm (50.3 inches)
Overall height1,219 mm (48.0 inches)
SeatRemovable Passenger Seat and Optional 3-in-1 Versatility
Rear tyre25/10-12
Front tyre25/8-12
Rear wheel travel254 mm (10.0 inches)
Rear SuspensionDouble A-Arm
Front wheel travel254 mm (10.0 inches)
Front SuspensionDouble A-Arm
Valves per cylinder4
Bore x Stroke102.0 x 85.0 mm (4.0 x 3.3 inches)
Color optionsTitanium/red/black
StarterElectric
