Benelli Tornado Tre 903 LE - 2011 Specifications and Reviews
2011
General information | |
| Category: | Sport |
| Year: | 2011 |
| Model: | Benelli Tornado Tre 903 LE |
Engine and Transmission Specifications | |
| Driveline: | Primary gears, final chain |
| Clutch: | Dry clutch with anti-blocking system |
| Transmission type,final drive: | Chain |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Ignition: | Electronic |
| Fuel control: | DOHC |
| Fuel system: | Injection. Electronic injection with three throttle bodies 53 mm |
| Valves per cylinder: | 4 |
| Bore x stroke: | 88.0 x 49.2 mm (3.5 x 1.9 inches) |
| Compression: | 12.5:1 |
| Torque: | 100.00 Nm (10.2 kgf-m or 73.8 ft.lbs) @ 8500 |
| Power: | 140.81 |
| Engine details: | Anti-vibration countershaft |
| Engine type: | In-line three, four-stroke |
| Capacity: | 898.00 ccm (54.80 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels: | Marchesini in forged aluminium |
| Rear brakes diameter: | 240 mm (9.4 inches) |
| Rear brakes: | Single disc |
| Front brakes diameter: | 320 mm (12.6 inches) |
| Front brakes: | Single disc |
| Rear tyre dimensions: | 180/55-ZR17 |
| Front tyre dimensions: | 120/70-ZR17 |
| Rear suspension travel: | 144 mm (5.7 inches) |
| Rear suspension: | Ohlins |
| Front suspension travel: | 150 mm (5.9 inches) |
| Front suspension: | Ohlins |
| Trail: | 95 mm (3.7 inches) |
| Rake (fork angle): | 23.5° |
| Frame type: | ASD tubular CrMo steel front, rear hollow cast aluminium box section |
Physical measures and capacities | |
| Fuel capacity: | 22.00 litres (5.81 gallons) |
| Wheelbase: | 1,419 mm (55.9 inches) |
| Seat height: | 810 mm (31.9 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.7611 HP/kg |
| Dry weight: | 185.0 kg (407.9 pounds) |
Other specs | |
| Comments: | Power Steering |
| Carrying capacity: | Front Rack Capacity 100 lbs / 45.4 kg. Rear Rack Capacity 50 lbs / 22.7 kg. Towing Capacity 1,050 lbs / 476.3 kg |
| Wheelbase: | 1,473 mm (58.0 inches) |
| Ground clearance: | 1,278 mm (50.3 inches) |
| Overall width: | 1,206 mm (47.5 inches) |
| Overall length: | 2,504 mm (98.6 inches) |
| Overall height: | 1,219 mm (48.0 inches) |
| Seat: | Removable Passenger Seat and Optional 3-in-1 Versatility |
| Rear tyre: | 25/10-12 |
| Front tyre: | 25/8-12 |
| Rear wheel travel: | 254 mm (10.0 inches) |
| Rear Suspension: | Double A-Arm |
| Front wheel travel: | 254 mm (10.0 inches) |
| Front Suspension: | Double A-Arm |
| Valves per cylinder: | 4 |
| Bore x Stroke: | 102.0 x 85.0 mm (4.0 x 3.3 inches) |
| Color options: | Green |
| Starter: | Electric |
