Benelli Tornado Tre 903 LE - 2011 Specifications and Reviews
2011
General information | |
| Category | Sport |
| Year | 2011 |
| Model | Benelli Tornado Tre 903 LE |
| | |
Engine and Transmission Specifications | |
| Driveline | Primary gears, final chain |
| Clutch | Dry clutch with anti-blocking system |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Ignition | Electronic |
| Fuel control | DOHC |
| Fuel system | Injection. Electronic injection with three throttle bodies 53 mm |
| Valves per cylinder | 4 |
| Bore x stroke | 88.0 x 49.2 mm (3.5 x 1.9 inches) |
| Compression | 12.5:1 |
| Torque | 100.00 Nm (10.2 kgf-m or 73.8 ft.lbs) @ 8500 |
| Power | 140.81 |
| Engine details | Anti-vibration countershaft |
| Engine type | In-line three, four-stroke |
| Capacity: | 898.00 ccm (54.80 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Marchesini in forged aluminium |
| Rear brakes diameter | 240 mm (9.4 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 320 mm (12.6 inches) |
| Front brakes | Single disc |
| Rear tyre dimensions | 180/55-ZR17 |
| Front tyre dimensions | 120/70-ZR17 |
| Rear suspension travel | 144 mm (5.7 inches) |
| Rear suspension | Ohlins |
| Front suspension travel | 150 mm (5.9 inches) |
| Front suspension | Ohlins |
| Trail | 95 mm (3.7 inches) |
| Rake (fork angle) | 23.5° |
| Frame type | ASD tubular CrMo steel front, rear hollow cast aluminium box section |
Physical measures and capacities | |
| Fuel capacity | 22.00 litres (5.81 gallons) |
| Wheelbase | 1,419 mm (55.9 inches) |
| Seat height | 810 mm (31.9 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.7611 HP/kg |
| Dry weight | 185.0 kg (407.9 pounds) |
Other specs | |
| Comments | Power Steering |
| Carrying capacity | Front Rack Capacity 100 lbs / 45.4 kg. Rear Rack Capacity 50 lbs / 22.7 kg. Towing Capacity 1,050 lbs / 476.3 kg |
| Wheelbase | 1,473 mm (58.0 inches) |
| Ground clearance | 1,278 mm (50.3 inches) |
| Overall width | 1,206 mm (47.5 inches) |
| Overall length | 2,504 mm (98.6 inches) |
| Overall height | 1,219 mm (48.0 inches) |
| Seat | Removable Passenger Seat and Optional 3-in-1 Versatility |
| Rear tyre | 25/10-12 |
| Front tyre | 25/8-12 |
| Rear wheel travel | 254 mm (10.0 inches) |
| Rear Suspension | Double A-Arm |
| Front wheel travel | 254 mm (10.0 inches) |
| Front Suspension | Double A-Arm |
| Valves per cylinder | 4 |
| Bore x Stroke | 102.0 x 85.0 mm (4.0 x 3.3 inches) |
| Color options | Green |
| Starter | Electric |
