Big Bear Choppers Merc Rigid 111 Carb - 2015 Specifications and Reviews

2015
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2015
Model:Big Bear Choppers Merc Rigid 111 Carb


Engine and Transmission Specifications

Exhaust system:Chrome Tuned Exhaust
Transmission type,final drive:Chain
Gearbox:5-speed
Lubrication system:S and S high volume oil pump
Ignition:S and S
Fuel system:Carburettor. S and S Super E Carburetor
Bore x Stroke:104.8 x 104.8 mm (4.1 x 4.1 inches)
Torque:166.52 Nm (17.0 kgf-m or 122.8 ft.lbs)
Power:115.80 Horsepower">HP (84.5 Kilowatt">kW))
Engine type:V2, four-stroke


Brakes, suspension, Frame and wheels

Rear brakes:Single disc. 4-piston caliper
Front brakes:Single disc. 4-piston calipers
Rear tyre:250/80-18
Front tyre:90/80-21
Rear wheel travel:76 mm (3.0 inches)
Rear Suspension:Rigid
Front wheel travel:76 mm (3.0 inches)
Front Suspension:BBC Merc Springer
Trail:95 mm (3.8 inches)
Rake (fork angle):48.0°
Frame type:BBC Merc Rigid

Physical measures and capacities

Oil capacity:4.70 litres (0.31 quarts)
Fuel capacity:14.66 litres (3.87 gallons)
Wheelbase:2,235 mm (88.0 inches)
Overall length:2,946 mm (116.0 inches)
Seat height:584 mm (23.0 inches) If adjustable, lowest setting.
Power/weight ratio:0.3928 HP/kg
Dry weight:294.8 kg (650.0 pounds)

Other specs

Comments:Also available as a kit.
Instruments:Chrome Digital Dash
Starter:Electric
Color options:Gross Black, satin black, charcoal metallic, silver metallic, black cherry, candy red metallic, firecracker red, orange pearl, electric blue. Standard or Custom Paint Scheme.
