Bimota Tesi 3D RaceCafe - 2017 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryNaked bike
Year2017
ModelBimota Tesi 3D RaceCafe

Engine and Transmission Specifications

ClutchDry Clutch, multi-disc
Transmission type,final driveChain
Gearbox6-speed
Cooling systemOil & air
Fuel controlDesmodromic valve control
Fuel systemInjection. Bimota by Athena/Electronic
Valves per cylinder2
Bore x Stroke88.0 x 66.0 mm (3.5 x 2.6 inches)
Compression11.1:1
Engine detailsDucati L-Twin
Engine typeV2, four-stroke
Capacity:803.00 ccm (49.00 cubic inches)



Brakes, suspension, Frame and wheels

WheelsForged Aluminium Alloy, black
Rear brakes diameter220 mm (8.7 inches)
Rear brakesSingle disc. Brembo, 2-piston
Front brakes diameter320 mm (12.6 inches)
Front brakesDouble disc. Brembo 4-piston, four separates pads, radial pump
Rear tyre180/55-ZR17
Front tyre120/70-ZR17
Rear SuspensionÖhlins monoshock with adjustable spring preload, compression and rebound, adjustable rear end height +/-14mm
Front SuspensionÖhlins monoshock with adjustable spring preload, compression and rebound, adjustable front end height +/-9,5mm
Frame typeAlu alloy plates, front and rear swingers in 25NiCrMo4 steel. Adjustable height +/-23mm

Physical measures and capacities

Fuel capacity16.00 litres (4.23 gallons)
Wheelbase1,390 mm (54.7 inches)
Overall width700 mm (27.6 inches)
Overall length2,100 mm (82.7 inches)
Overall height1,100 mm (43.3 inches)
Alternate seat height803 mm (31.6 inches) If adjustable, highest setting.
Seat height757 mm (29.8 inches) If adjustable, lowest setting.
Dry weight165.0 kg (363.8 pounds)



Other specs

CommentsItalian brand.
StarterElectric
Color optionsWhite/black/brown
