General information | |
| Category | Sport |
| Year | 2010 |
| Model | Ducati 1198 S |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Lightweight 2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers |
| Clutch | Dry multiplate with hydraulic control |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Fuel control | Desmodromic valve control |
| Fuel system | Injection. Marelli electronic fuel injection, elliptical throttle bodies. |
| Valves per cylinder | 4 |
| Bore x stroke | 106.0 x 67.9 mm (4.2 x 2.7 inches) |
| Compression | 12.7:1 |
| Torque | 131.53 Nm (13.4 kgf-m or 97.0 ft.lbs) @ 8000 |
| Power | 170.00 |
| Engine type | V2, four-stroke |
| Capacity: | 1198.40 ccm (73.13 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 245 mm (9.6 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 330 mm (13.0 inches) |
| Front brakes | Double disc |
| Rear tyre dimensions | 190/55-ZR17 |
| Front tyre dimensions | 120/70-ZR17 |
| Rear suspension | Progressive linkage with fully adjustable Ohlins monoshock with top-out spring. Aluminium single-sided swingarm |
| Front suspension | Ohlins 43mm fully adjustable usd forks with TiN |
| Rake (fork angle) | 24.5° |
| Frame type | Tubular steel Trellis frame in ALS 450 |
Physical measures and capacities | |
| Fuel capacity | 15.50 litres (4.10 gallons) |
| Wheelbase | 1,430 mm (56.3 inches) |
| Seat height | 820 mm (32.3 inches) If adjustable, lowest setting. |
| Power/weight ratio | 1.0059 HP/kg |
| Dry weight | 169.0 kg (372.6 pounds) |
Other specs | |
| Color options | White, black, red |
