Ducati Hypermotard 939 SP - 2017 Specifications and Reviews
General information | |
| Category | Super motard |
| Year | 2017 |
| Model | Ducati Hypermotard 939 SP |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Single stainless steel muffler with catalytic converter and two lambda probes. |
| Emission details | Euro 4 |
| Driveline | Chain, Front sprocket 15, Rear sprocket 45. Primary drive: Straight cut gears, Ratio 1.85. |
| Clutch | Slipper and self-servo wet multiplate clutch mechanically operated |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Fuel control | Desmodromic valve control |
| Fuel system | Injection. Throttle bodies with full Ride by Wire system |
| Valves per cylinder | 4 |
| Bore x Stroke | 94.0 x 67.5 mm (3.7 x 2.7 inches) |
| Compression | 13.1:1 |
| Torque | 97.70 Nm (10.0 kgf-m or 72.1 ft.lbs) @ 7500 Revolutions">RPM |
| Power | 113.00 Horsepower">HP (82.5 Kilowatt">kW)) @ 9500 Revolutions">RPM |
| Engine details | Testastretta 11° L-Twin |
| Engine type | V2, four-stroke |
| Capacity: | 937.00 ccm (57.18 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | 3-spoke forged light alloy. Pirelli Diablo Supercorsa tyres. |
| Rear brakes diameter | 245 mm (9.6 inches) |
| Rear brakes | Single disc. ABS. Two-piston calipers. |
| Front brakes diameter | 320 mm (12.6 inches) |
| Front brakes | Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted. |
| Rear tyre | 180/55-ZR17 |
| Front tyre | 120/70-ZR17 |
| Rear wheel travel | 175 mm (6.9 inches) |
| Rear Suspension | Progressive linkage with fully adjustable Ohlins monoshock. Aluminium single-sided swingarm |
| Front wheel travel | 185 mm (7.3 inches) |
| Front Suspension | Ohlins fully adjustable 48mm usd forks |
| Trail | 104 mm (4.1 inches) |
| Rake (fork angle) | 25.5° |
| Frame type | Tubular steel trellis |
Physical measures and capacities | |
| Fuel capacity | 16.00 litres (4.23 gallons) |
| Wheelbase | 1,498 mm (59.0 inches) |
| Overall width | 860 mm (33.9 inches) |
| Overall length | 2,110 mm (83.1 inches) |
| Seat height | 890 mm (35.0 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.6348 HP/kg |
| Weight incl. oil, gas, etc | 201.0 kg (443.1 pounds) |
| Dry weight | 178.0 kg (392.4 pounds) |
Other specs | |
| Factory warranty | 2 years unlimited mileage |
| Instruments | Multifunction digital dashboard with white backlight, composed of LCD segments for rev counter and a Dot-Matrix area for all other information. |
| Starter | Electric |
| Color options | Red Corse Stripe/White |
