Ducati Monster 1200 - 2017 Specifications and Reviews
General information | |
| Category | Naked bike |
| Year | 2017 |
| Model | Ducati Monster 1200 |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers |
| Emission details | Euro 3 |
| Driveline | Front sprocket 15; Rear sprocket 41. Primary drive: Straight cut gears, ratio 1.84. |
| Clutch | Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run. |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Fuel control | Desmodromic valve control |
| Fuel system | Injection. 53mm throttle bodies with full Ride by Wire |
| Valves per cylinder | 4 |
| Bore x Stroke | 106.0 x 67.9 mm (4.2 x 2.7 inches) |
| Compression | 12.5:1 |
| Torque | 118.00 Nm (12.0 kgf-m or 87.0 ft.lbs) @ 7250 Revolutions">RPM |
| Power | 135.00 Horsepower">HP (98.5 Kilowatt">kW)) @ 8750 Revolutions">RPM |
| Engine details | Testastretta 11° L-Twin |
| Engine type | V2, four-stroke |
| Capacity: | 1198.40 ccm (73.13 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Seat | Dual seat |
| Rear brakes diameter | 245 mm (9.6 inches) |
| Rear brakes | Single disc. ABS. Floating disc. Two-piston calipers. |
| Front brakes diameter | 320 mm (12.6 inches) |
| Front brakes | Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted. |
| Rear tyre | 190/55-ZR17 |
| Front tyre | 120/70-ZR17 |
| Rear wheel travel | 152 mm (6.0 inches) |
| Rear Suspension | Progressive linkage with fully adjustable monoshock. Aluminium single-sided swingarm |
| Front wheel travel | 130 mm (5.1 inches) |
| Front Suspension | 43mm fully adjustable usd forks |
| Trail | 93 mm (3.7 inches) |
| Rake (fork angle) | 24.3° |
| Frame type | Tubular steel Trellis frame attached to the cylinders head |
Physical measures and capacities | |
| Fuel capacity | 17.50 litres (4.62 gallons) |
| Wheelbase | 1,511 mm (59.5 inches) |
| Overall width | 1,040 mm (40.9 inches) |
| Overall length | 2,200 mm (86.6 inches) |
| Overall height | 830 mm (32.7 inches) |
| Seat height | 785 mm (30.9 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.7418 HP/kg |
| Weight incl. oil, gas, etc | 209.0 kg (460.8 pounds) |
| Dry weight | 182.0 kg (401.2 pounds) |
Other specs | |
| Factory warranty | 2 years unlimited mileage |
| Instruments | Colour TFT display |
| Starter | Electric |
| Color options | Red, grey |
