Category: | Touring |
Year: | 2010 |
Model: | Harley-Davidson FLHRC Road King Classic |
Engine and Transmission Specifications |
Exhaust system: | 2-1-2 chrome exhaust with dual mufflers |
Transmission type,final drive: | Belt |
Gearbox: | 6-speed |
Cooling system: | Air |
Fuel system: | Injection. Electronic Sequential Port Fuel Injection |
Valves per cylinder: | 2 |
Bore x stroke: | 95.3 x 111.1 mm (3.8 x 4.4 inches) |
Compression: | 9.2:1 |
Torque: | 127.00 Nm (12.9 kgf-m or 93.7 ft.lbs) @ 3500 |
Engine type: | V2, four-stroke |
Capacity: | 1584.00 ccm (96.66 cubic inches) |
Brakes, suspension, Frame and wheels |
Rear brakes diameter: | 300 mm (11.8 inches) |
Rear brakes: | Single disc. 4-piston fixed caliper |
Front brakes diameter: | 300 mm (11.8 inches) |
Front brakes: | Double disc. 4-piston fixed caliper |
Rear suspension travel: | 76 mm (3.0 inches) |
Rear suspension: | Air-adjustable |
Front suspension travel: | 117 mm (4.6 inches) |
Front suspension: | 41.3mm telescopic |
Trail: | 170 mm (6.7 inches) |
Rake (fork angle): | 26.0° |
Frame type: | Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame. |
|
Physical measures and capacities |
Oil capacity: | 3.50 litres (0.23 quarts) |
Fuel capacity: | 22.70 litres (6.00 gallons) |
Wheelbase: | 1,625 mm (64.0 inches) |
Ground clearance: | 146 mm (5.7 inches) |
Overall length: | 2,400 mm (94.5 inches) |
Seat height: | 735 mm (28.9 inches) If adjustable, lowest setting. |
Dry weight: | 355.0 kg (782.6 pounds) |
Other specs |
Color options: | Vivid Black, Brilliant Silver Pearl, Flame Blue Pearl, Red Hot Sunglo |
Starter: | Electric |
