Harley-Davidson FLHRC Road King Classic - 2010 Specifications and Reviews
The 2010 Harley-Davidson FLHRC Road King Classic is a heavyweight touring cruiser designed for riders seeking classic styling with modern comfort on long-distance rides. Powered by a 1584cc Twin-Cam V-twin engine producing 127 Nm of torque, it combines iconic retro aesthetics with reliable performance and touring capability. Known for its comfortable seating position, extensive chrome detailing, and legendary Harley heritage, it appeals to experienced cruiser enthusiasts who value tradition and presence on the road.
General information | |
| Category | Touring |
| Year | 2010 |
| Model | Harley-Davidson FLHRC Road King Classic |
| | |
Engine and Transmission Specifications | |
| Exhaust system | 2-1-2 chrome exhaust with dual mufflers |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection |
| Valves per cylinder | 2 |
| Bore x stroke | 95.3 x 111.1 mm (3.8 x 4.4 inches) |
| Compression | 9.2:1 |
| Torque | 127.00 Nm (12.9 kgf-m or 93.7 ft.lbs) @ 3500 |
| Engine type | V2, four-stroke |
| Capacity: | 1584.00 ccm (96.66 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 300 mm (11.8 inches) |
| Rear brakes | Single disc. 4-piston fixed caliper |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Double disc. 4-piston fixed caliper |
| Rear suspension travel | 76 mm (3.0 inches) |
| Rear suspension | Air-adjustable |
| Front suspension travel | 117 mm (4.6 inches) |
| Front suspension | 41.3mm telescopic |
| Trail | 170 mm (6.7 inches) |
| Rake (fork angle) | 26.0° |
| Frame type | Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame. |
Physical measures and capacities | |
| Oil capacity | 3.50 litres (0.23 quarts) |
| Fuel capacity | 22.70 litres (6.00 gallons) |
| Wheelbase | 1,625 mm (64.0 inches) |
| Ground clearance | 146 mm (5.7 inches) |
| Overall length | 2,400 mm (94.5 inches) |
| Seat height | 735 mm (28.9 inches) If adjustable, lowest setting. |
| Dry weight | 355.0 kg (782.6 pounds) |
Other specs | |
| Maintenance | Find parts, fluids, filters, maintenance tools and service items on eBay |
| Color options | Vivid Black, Brilliant Silver Pearl, Flame Blue Pearl, Red Hot Sunglo |
| Starter | Electric |
Performance Profile & Rider Fit
Best For
Rider Profile
| Best For | Best suited to riders who already have experience handling heavy, low-slung cruisers and are comfortable managing significant weight at low speeds. |
| Purpose | Built for long-distance highway touring in classic cruiser style, prioritizing relaxed cruising and load-carrying over outright speed or sportiness. |
| Rider Fit | The low seat height makes it accessible for shorter riders, but the substantial wet weight of over 360 kg demands confident low-speed balance and upper body strength when maneuvering or parking. |
| Character | A traditional, torque-rich air-cooled V-twin cruiser with chrome styling and a laid-back riding position that rewards patience over aggression. |
| Not Ideal For | Not suited for riders seeking sharp cornering agility, high-speed performance, or any kind of off-road capability. |
Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.
⚠ Safety Recalls (3)
Harley-Davidson Motor Company (Harley-Davidson) is recalling all 2008-2011 Touring, CVO Touring and VSRC motorcycles equipped with anti-lock brakes (ABS), including Road King (FLHR), Road King Police (EFI) (FLHP), Road King Police (EFI) (FLHPE), Electra Glide Standard Police (EFI) (FLHTP), Electra Glide Classic (EFI) (FLHTC), Electra Glide Ultra Classic (EFI) (FLHTCU) and Street Glide (EFI) (FLHX), 2008 VROD (VRSCAWA), CVO Road King 4 (FLHRSE4), Night Rod (VRSCDA), CVO Ultra Classic 3 (FLHTCUSE3), Night Rod Special (VRSCDXA), 2008-2010 Road King Classic (EFI) (FLHRC), 2008-2009 Road Glide (EFI) (FLTR) and Electra Glide Standard (EFI) (FLHT), 2009-2010 V-Rod (VRSCAW), 2009 CVO Ultra Classic (FLHTCUSE4) and CVO Road Glide 3 (FLTRSE3), 2009-2011 Night Rod Special (VRSCDX) and V-Rod Muscle (VRSCF), 2010 CVO Ultra Classic 5 (FLHTCUSE5) and CVO Street Glide (FLHXSE), 2010-2011 Electra Glide Ultra Limited (FLHTK) and Road Glide Custom (FLTRX), 2011 Road Glide Ultra 103 (FLTRU103), Street Glide 103 (FLHX103), Road King Classic 103 (FLHRC103), CVO Ultra Classic 6 (FLHTCUSE6), CVO Road Glide Ultra (FLTRUSE), Road Glide Custom 103 (FLTRX103), and CVO Street Glide 2 (FLHXSE2) motorcycles. Deposits may form on components within the brake system if the DOT 4 brake fluid is not replaced for a prolonged period of time beyond the 2-year maintenance schedule specified in the OwnerÂ’s Manual.
Risk: These deposits may cause a valve within the ABS Hydraulic Control Unit to stick, reducing braking ability and increasing the risk of a crash.
Remedy: Harley-Davidson will notify owners, and dealers will flush the entire brake system with new Platinum Label DOT 4 brake fluid, free of charge. The recall began on February 14, 2018. Owners may contact Harley-Davidson customer service at 1-800-258-2464. Harley-Davidson's number for this recall is 0171.
HARLEY-DAVIDSON IS RECALLING CERTAIN MODEL YEAR 2009-2012 TOURING, CVO TOURING AND TRIKE VEHICLES MANUFACTURED FROM JUNE 6, 2008, THROUGH SEPTEMBER 16, 2011. SEE THE ABOVE LIST FOR THE MODELS INCLUDED IN THE RECALL. THE REAR BRAKE LIGHT SWITCH MAY BE EXPOSED TO EXCESSIVE HEAT FROM THE EXHAUST SYSTEM.
Risk: THE EXCESSIVE HEAT MAY CAUSE THE SWITCH TO NOT ACTIVATE THE BRAKE LAMP OR ACTIVATE THE BRAKE LAMP WHEN NO BRAKE IS APPLIED AND/OR CAUSE A BRAKE FLUID LEAK AT THE BRAKE LIGHT SWITCH, AFFECTING REAR BRAKE PERFORMANCE. EITHER CONDITION MAY INCREASE THE RISK OF A CRASH.
Remedy: HARLEY-DAVIDSON WILL NOTIFY OWNERS, AND DEALERS WILL A INSTALL A REAR BRAKE LIGHT SWITCH KIT, FREE OF CHARGE. THE SAFETY RECALL IS EXPECTED TO BEGIN DURING OCTOBER 31, 2011. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.
HARLEY-DAVIDSON IS RECALLING CERTAIN MODEL YEAR 2009 AND 2010 TOURING FAMILY MOTORCYCLES, INCLUDING CVO TOURING AND TRIKE PRODUCTS, MANUFACTURED FROM JUNE 6, 2008 THROUGH NOVEMBER 19, 2009. THE FRONT FUEL TANK MOUNTS MAY DISTORT IN REACTION TO SEVERE FRAME DAMAGE FROM A FRONTAL COLLISION. THIS CONDITION MAY CAUSE A FUEL LEAK AT THE WELD OF THE FRONT BRACKET TO THE TUNNEL.
Risk: A FUEL LEAK IN THE PRESENCE OF AN IGNITION SOURCE MAY RESULT IN A FIRE, WHICH COULD LEAD TO INJURY OR DEATH TO THE RIDER.
Remedy: DEALERS WILL INSTALL A LEFT AND RIGHT BRACE, WHICH ARE INTENDED TO REDUCE FRONT MOUNT DISTORTION DURING CERTAIN CRASH CONDITIONS. THIS REPAIR WILL BE PERFORMED FREE OF CHARGE. THE SAFETY RECALL BEGAN ON DECEMBER 11, 2009. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.
Source: NHTSA. View all Harley-Davidson recalls →
