Harley-Davidson FLHR Road King - 2002 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Touring
Year:2002
Model:Harley-Davidson FLHR Road King


Engine and Transmission Specifications

Transmission typefinal drive:Belt
Cooling system:Air
Fuel system:Carburettor
Bore x stroke:95.3 x 101.6 mm (3.8 x 4.0 inches)
Compression:8.8:1
Torque:110.00
Stroke:4
Engine type:V2
Capacity:1449.00 ccm (88.42 cubic inches)

Physical measures and capacities

Wheelbase:1,592 mm (62.7 inches)
Ground clearance:130 mm (5.1 inches)
Overall length:2,440 mm (96.1 inches)
Seat height:693 mm (27.3 inches) If adjustable, lowest setting.
Dry weight:345.0 kg (760.6 pounds)

Harley-Davidson FLHR Road King dimensions and frame

Rear brakes diameter:292 mm (11.5 inches)
Rear brakes:Single disc
Front brakes diameter:292 mm (11.5 inches)
Front brakes:Dual disc


Speed and acceleration

Reserve fuel capacity:3.40 litres (0.90 gallons)
Fuel capacity:18.90 litres (4.99 gallons)
