Touring Motorcycles

2003Harley-Davidson Flhtcui Ultra Classic Electra Glide

30 fields on record

The 2003 Harley-Davidson FLHTCUI Ultra Classic Electra Glide is a full-featured touring cruiser designed for long-distance comfort and highway dominance. Its air-cooled 1449cc V-twin engine delivers abundant low-end torque, while comprehensive touring amenities make it ideal for riders seeking laid-back luxury cruising on extended journeys.

Capacity: 1449.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 5-speed
Dry weight: 345.0 kg
Seat height: 735 mm
Power: 67.0 HP (49.3 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (2)

What’s new for the 2003 Harley-Davidson Flhtcui Ultra Classic Electra Glide

vs the 2002

Spec	2002	2003
Engine capacity	1450.0 ccm (88.48 cubic inches)	1449.0 ccm (88.42 cubic inches)
Torque	109.5 Nm (11.2 kgf-m or 80.8 ft.lbs)	110.0 Nm (11.2 kgf-m or 81.1 ft.lbs)
Dry weight	385.0 kg (848.8 pounds)	345.0 kg (760.6 pounds)
Seat height	693 mm (27.3 inches)	735 mm (28.9 inches)
Fuel capacity	18.90 litres (4.99 US gallons)	18.80 litres (4.97 US gallons)
Front brakes	Dual disc	not listed

Other years 2000 2001 2002 2003 2004 2005 2006

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding35%

Daily riding55%

Touring97%

Two-up95%

Track5%

Best for: Built for effortless long-distance highway touring with full weather protection, storage, and passenger comfort rather than outright performance.
Built for: A stately, torque-rich classic cruiser that rewards relaxed, smooth riding with deep V-twin character and old-school Harley presence.
Not ideal for: Not for riders seeking sharp cornering agility, off-road capability, or lightweight, nimble city commuting.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 735mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2003 Harley-Davidson Flhtcui Ultra Classic Electra Glide, with a cramped knee angle of around 80 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1449.0 ccm
Power: 67.0 HP (49.3 kW)
Torque: 110.0 Nm (11.2 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.1942 HP/kg
Bore x stroke: 95.3 x 101.6 mm
Compression: 8.8:1
Cooling system: Air
Fuel system: Injection
Starting: Electric
Valves per cylinder: 2

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1592 mm
Overall length: 2500 mm
Seat height: 735 mm
Dry weight: 345.0 kg
Fuel capacity: 18.80 litres
Ground clearance: 130 mm

Chassis & suspension

Rake (fork angle): 26.0°
Trail: 158 mm

Brakes & wheels

Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: 90/90-16
Rear tyre: 150/85-16

Other

Color options: 2-tone sterling silver & vivid black, vivid black, gunmetal pearl, luxury rich red pearl, white pearl, luxury blue pearl

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2000	2002	2003	2005	2006
Capacity	1499.00 ccm (91.47 cubic inches)	1450.00 ccm (88.48 cubic inches)	1449.00 ccm (88.42 cubic inches)	1449.00 ccm (88.42 cubic inches)	1442.15 ccm (88.00 cubic inches)
Dry weight	385.0 kg (848.8 pounds)	385.0 kg (848.8 pounds)	345.0 kg (760.6 pounds)	385 kg (848.8 pounds)	357.4 kg (788.0 pounds)
Seat height	692 mm (27.2 inches)	693 mm (27.3 inches)	735 mm (28.9 inches)	693 mm (27.3 inches)	693 mm (27.3 inches)
Fuel capacity	18.90 litres (4.99 gallons)	18.90 litres (4.99 gallons)	18.80 litres (4.97 gallons)	18.90 litres (4.99 gallons)	18.92 litres (5.00 gallons)
Color options	Black, red, blue, blue/gray, orange/gray, red/black, green/black	—	2-tone sterling silver & vivid black, vivid black, gunmetal pearl, luxury rich red pearl, white pearl, luxury blue pearl	Vivid black, sierra red, luxury teal, luxury blue, glacier white pearl, lava red sunglo, two-tone luxury blue and impact blue, two-tone luxury teal and brilliant silver, two-tone sierra red and brilliant silver, two-tone smokey gold and vivid black	Vivid black, black cherry, black pearl, deep cobalt, glacier white pearl, rich sunglo blue, brandy wine sunglo, two-tone rich sunglo blue and chopper blue, two-tone chopper blue and brilliant silver, two-tone black cherry and black pearl, two-tone fire re

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 2 open recalls

EXTERIOR LIGHTING:TAIL LIGHTSMay 2004 · 04V218000

ON CERTAIN DYNA, XL, AND TOURING MOTORCYCLES, THE TAIL LIGHT BULB CAN FALL OUT OF THE SOCKET.

Risk: THE TAIL LIGHT AND THE BRAKE LIGHT BECOME INOPERATIVE, WHICH COULD LEAD TO A CRASH.

Remedy: DEALERS WILL REPLACE THE BULBS. OWNER NOTIFICATION BEGAN ON JUNE 3, 2004. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-342-4680.

ELECTRICAL SYSTEM:WIRING:FUSES AND CIRCUIT BREAKERSMar 2004 · 04V134000

ON CERTAIN TOURING AND POLICE MODEL MOTORCYCLES, THE 40 AMP MAIN CIRCUIT BREAKER CAN "OPEN" FOR REASONS OTHER THAN WHICH IT WAS DESIGNED, CAUSING AN UNEXPECTED INTERRUPTION OF ALL ELECTRICAL POWER TO THE MOTORCYCLE.

Risk: THIS CONDITION COULD CAUSE THE MOTORCYCLE TO STALL, WHICH COULD RESULT IN A CRASH.

Remedy: DEALERS WILL REPLACE THE CIRCUIT BREAKER. OWNER NOTIFICATION BEGAN APRIL 23, 2004. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

Source: NHTSA. View all Harley-Davidson recalls →
