Harley-Davidson FLHTCUSE4 CVO Ultra Classic Electra Glide - 2009 Specifications and Reviews
2009
General information | |
| Category: | Touring |
| Year: | 2009 |
| Model: | Harley-Davidson FLHTCUSE4 CVO Ultra Classic Electra Glide |
Engine and Transmission Specifications | |
| Clutch: | Hydraulically actuated, 9-plate wet, with high performance spring |
| Transmission typefinal drive: | Belt |
| Gearbox: | 6-speed |
| Cooling system: | Air |
| Starter: | Electric |
| Fuel system: | Injection. Electronic Sequential Port Fuel Injection |
| Bore x stroke: | 101.6 x 111.3 mm (4.0 x 4.4 inches) |
| Compression: | 9.2:1 |
| Torque: | 149.00 |
| Stroke: | 4 |
| Engine type: | V2 |
| Capacity: | 1800.00 ccm (109.84 cubic inches) |
Physical measures and capacities | |
| Wheelbase: | 1,614 mm (63.5 inches) |
| Ground clearance: | 130 mm (5.1 inches) |
| Overall length: | 2,494 mm (98.2 inches) |
| Seat height: | 696 mm (27.4 inches) If adjustable, lowest setting. |
| Dry weight: | 402.0 kg (886.3 pounds) |
Harley-Davidson FLHTCUSE4 CVO Ultra Classic Electra Glide dimensions and frame | |
| Exhaust system: | Chrome, dual exhaust with touring mufflers, |
| Rear brakes diameter: | 300 mm (11.8 inches) |
| Rear brakes: | Single disc. 2-piston calipers |
| Front brakes diameter: | 300 mm (11.8 inches) |
| Front brakes: | Double disc. 4-piston calipers |
| Rear tyre dimensions: | 180/65-B16 |
| Front tyre dimensions: | 130/80-B17 |
| Rear suspension travel: | 76 mm (3.0 inches) |
| Rear suspension: | Air-adjustable |
| Front suspension travel: | 117 mm (4.6 inches) |
| Front suspension: | 41.3 mm telescopic, cartridge-style damping |
| Trail: | 170 mm (6.7 inches) |
| Rake (fork angle): | 26.0° |
| Frame type: | New mild steel, single spar rigid backbone with |
Speed and acceleration | |
| Color options: | Ruby Red and Typhoon Maroon with Forge-tone graphics, Autumn Haze and High Octane Orange with Forge-tone graphics; Stardust Silver and Twilight Blue with Forge-tone graphics |
| Fuel capacity: | 22.70 litres (6.00 gallons) |
