Harley-Davidson FLHTCUSE5 CVO Ultra Classic Electra Glide - 2010 Specifications and Reviews

2010
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryTouring
Year2010
ModelHarley-Davidson FLHTCUSE5 CVO Ultra Classic Electra Glide



Engine and Transmission Specifications

Exhaust systemChrome, dual exhaust with touring mufflers,
ClutchHydraulically actuated, 9-plate wet, with high performance spring
Transmission type,final driveBelt
Gearbox6-speed
Cooling systemAir
Fuel systemInjection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke101.6 x 111.1 mm (4.0 x 4.4 inches)
Compression9.2:1
Torque151.00 Nm (15.4 kgf-m or 111.4 ft.lbs)
Engine typeV2, four-stroke
Capacity:1800.00 ccm (109.84 cubic inches)

Brakes, suspension, Frame and wheels

Rear brakes diameter300 mm (11.8 inches)
Rear brakesSingle disc
Front brakes diameter300 mm (11.8 inches)
Front brakesDouble disc
Rear tyre dimensions180/65-B16
Front tyre dimensions130/80-B17
Rear suspension travel76 mm (3.0 inches)
Rear suspensionAir-adjustable
Front suspension travel117 mm (4.6 inches)
Front suspension41.3mm telescopic, with blow-by valve
Trail170 mm (6.7 inches)
Rake (fork angle)26.0°
Frame typeMild steel; tubular frame, two-piece stamped and welded backbone; cast and forged junctions; twin down tubes; bolt-on rear frame with forged fender supports; MIG welded

Physical measures and capacities

Oil capacity3.50 litres (0.23 quarts)
Fuel capacity22.70 litres (6.00 gallons)
Wheelbase1,635 mm (64.4 inches)
Ground clearance125 mm (4.9 inches)
Overall length2,535 mm (99.8 inches)
Seat height755 mm (29.7 inches) If adjustable, lowest setting.
Dry weight407.0 kg (897.3 pounds)

Other specs

Color optionsScarlet Red Pearl/Dark Slate with Flame Graphics, Riptide Blue/Titanium Dust with Flame Graphics; Burnt Amber/ Hot Citrus with Flame Graphics
