Harley-Davidson FLHTK Electra Glide Ultra Limited - 2012 Specifications and Reviews
The 2012 Harley-Davidson FLHTK Electra Glide Ultra Limited is a premium touring cruiser designed for long-distance riders seeking maximum comfort and advanced technology. Known for its luxurious two-up seating, comprehensive electronic instrumentation including cruise control and engine diagnostics, and classic styling, it excels at highway cruising with a passenger. Its 22.7-liter fuel capacity and touring-focused design make it ideal for extended journeys.
General information | |
| Category | Touring |
| Year | 2012 |
| Model | Harley-Davidson FLHTK Electra Glide Ultra Limited |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, 2-1-2 dual exhaust with tapered mufflers |
| Greenhouse gases | 129.9 CO |
| Fuel consumption | 5.60 litres/100 km (17.9 km/l or 42.00 mpg) |
| Driveline | Primary drive chain, 34/46 ratio. Final Drive Belt, 32/68 ratio |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Lubrication system | Pressurized, dry-sump with oil cooler |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Valves per cylinder | 2 |
| Bore x stroke | 98.4 x 111.3 mm (3.9 x 4.4 inches) |
| Compression | 9.6:1 |
| Torque | 135.60 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3250 |
| Engine details | Air-cooled Twin Cam 103 with Integrated Oil-Cooler. Pushrod-operated, overhead valves with hydraulic, self-adjusting lifter. |
| Engine type | V2, four-stroke |
| Capacity: | 1687.97 ccm (103.00 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels | Black and Chrome, 28-spoke Cast Aluminum |
| Rear brakes diameter | 300 mm (11.8 inches) |
| Rear brakes | Single disc. 4-piston caliper. ABS. |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Double disc. 4-piston calipers. ABS. |
| Rear tyre dimensions | 180/65-NW16 |
| Front tyre dimensions | 130/80-NW17 |
| Rear suspension travel | 76 mm (3.0 inches) |
| Rear suspension | Air-adjustable shocks. Mild steel; two-piece drawn and welded section; forged junctions; MIG welded swingarm. |
| Front suspension travel | 117 mm (4.6 inches) |
| Front suspension | 41.3 mm telescopic, triple circuit damping |
| Trail | 170 mm (6.7 inches) |
| Rake (fork angle) | 26.0° |
| Frame type | Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded |
| | |
Physical measures and capacities | |
| Oil capacity | 3.80 litres (0.25 quarts) |
| Fuel capacity | 22.71 litres (6.00 gallons) |
| Wheelbase | 1,613 mm (63.5 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall length | 2,504 mm (98.6 inches) |
| Seat height | 693 mm (27.3 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 408.7 kg (901.0 pounds) |
| Dry weight | 388.7 kg (857.0 pounds) |
Other specs | |
| Comments | French brand. |
| Wheelbase | 1,285 mm (50.6 inches) |
| Overall width | 685 mm (27.0 inches) |
| Overall height | 1,150 mm (45.3 inches) |
| Power/weight ratio | 0.0472 HP/kg |
| Rear tyre | 3.00-12 |
| Front tyre | 2.50-12 |
| Ignition | CDI |
| Torque | 4.00 Nm (0.4 kgf-m or 3.0 ft.lbs) @ 5500 Revolutions">RPM |
| Power | 4.15 Horsepower">HP (3.0 Kilowatt">kW)) @ 8000 Revolutions">RPM |
| Capacity: | 49.20 ccm (3.00 cubic inches) |
| Model | Goes G 55 R Sport |
| Color options | Vivid Black, Big Blue Pearl/Vivid Black, Ember Red Sunglo/Merlot Sunglo, Midnight Pearl/Brilliant Silver Pearl, Tequila Sunrise/H-D Orange |
| Factory warranty | 2 years, unlimited mileage. |
| Seat | One-piece, two-up Electra Glide classic comfort stitch seat, sculpted for added comfort and easier straddling. Passenger backrest with wrap-around armrests. |
| Electrical | Sealed, maintenance-free battery, 12V, 28-amp/hour, 370 cca |
| Instruments | Fairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light; cruise control indicator light; tachometer with fuel, voltage, oil pressure and ambient air temperature gauges |
| Starter | Electric |
Rider Reviews
Add a Comment
Related Motorcycle Specifications
More Harley-Davidson Motorcycles
⚠ Safety Recalls (1)
HARLEY-DAVIDSON IS RECALLING CERTAIN MODEL YEAR 2009-2012 TOURING, CVO TOURING AND TRIKE VEHICLES MANUFACTURED FROM JUNE 6, 2008, THROUGH SEPTEMBER 16, 2011. SEE THE ABOVE LIST FOR THE MODELS INCLUDED IN THE RECALL. THE REAR BRAKE LIGHT SWITCH MAY BE EXPOSED TO EXCESSIVE HEAT FROM THE EXHAUST SYSTEM.
Risk: THE EXCESSIVE HEAT MAY CAUSE THE SWITCH TO NOT ACTIVATE THE BRAKE LAMP OR ACTIVATE THE BRAKE LAMP WHEN NO BRAKE IS APPLIED AND/OR CAUSE A BRAKE FLUID LEAK AT THE BRAKE LIGHT SWITCH, AFFECTING REAR BRAKE PERFORMANCE. EITHER CONDITION MAY INCREASE THE RISK OF A CRASH.
Remedy: HARLEY-DAVIDSON WILL NOTIFY OWNERS, AND DEALERS WILL A INSTALL A REAR BRAKE LIGHT SWITCH KIT, FREE OF CHARGE. THE SAFETY RECALL IS EXPECTED TO BEGIN DURING OCTOBER 31, 2011. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.
Source: NHTSA. View all Harley-Davidson recalls →
