Touring Motorcycles

2012Harley-Davidson FLHX Street Glide

Rate this bike

43 fields on record

The 2012 Harley-Davidson FLHX Street Glide is a full-size cruiser designed for riders seeking long-distance comfort and classic touring capability. Known for its distinctive batwing fairing, sculpted comfort seat, and comprehensive electronic instrumentation, it excels at highway cruising while maintaining iconic Harley styling. The bike suits experienced riders who prioritize comfort and technology on extended journeys.

Capacity: 1688.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 356.1 kg
Seat height: 663 mm
Power: 86.0 HP (63.3 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (1)

What’s new for the 2012 Harley-Davidson FLHX Street Glide

vs the 2011

Spec	2011	2012
Engine capacity	1584.0 ccm (96.66 cubic inches)	1688.0 ccm (103.01 cubic inches)
Power	75.0 HP (55.2 kW)	86.0 HP (63.3 kW)
Torque	126.0 Nm (12.8 kgf-m or 92.9 ft.lbs) @ 3500 RPM	135.6 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3250 RPM
Seat height	715 mm (28.1 inches)	663 mm (26.1 inches)
Front suspension	41.3mm telescopic, triple circuit damping	41.3 mm telescopic, triple circuit damping
Rear suspension	Short, air-adjustable	Air-adjustable shocks. Mild steel; two-piece drawn and welded section; forged junctions; MIG welded swingarm.
Front brakes	Double disc. 4-piston fixed caliper	Double disc. 4-piston calipers. Optional ABS.
Rear brakes	Single disc. 4-piston fixed caliper	Single disc. 4-piston caliper. Optional ABS.
Compression	9.2:1	9.6:1

Other years 2006 2007 2008 2009 2010 2011 2012

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding35%

Daily riding55%

Touring95%

Two-up85%

Track5%

Best for: Built for covering long highway miles in comfort with a bold, iconic American V-twin presence rather than for outright speed or sport handling.
Built for: A classic bagger persona: torque-rich, unhurried, and styled for cruising boulevards or interstates with commanding road presence.
Not ideal for: Not a good fit for riders seeking sharp cornering agility, off-road capability, or a lightweight, nimble city commuter.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 663mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2012 Harley-Davidson FLHX Street Glide, with a cramped knee angle of around 70 degrees and a slightly forward riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1688.0 ccm
Power: 86.0 HP (63.3 kW)
CO2 Emissions: 130 CO2 g/km
Torque: 135.6 Nm (13.8 kgf-m) @ 3250 RPM
Engine type: V-Twin, four-stroke
Fuel consumption: 5.60 litres/100 km (17.9 km/l)
Power/weight ratio: 0.2415 HP/kg (dry)
Bore x stroke: 95.3 x 111.3 mm
Compression: 9.6:1
Cooling system: Air
Fuel system: Injection
Starting: Electric
Valves per cylinder: 2
Lubrication system: Pressurized, dry-sump with oil cooler

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1613 mm
Overall length: 2413 mm
Seat height: 663 mm
Dry weight: 356.1 kg
Wet weight: 372.9 kg
Fuel capacity: 22.70 litres
Ground clearance: 119 mm
Oil capacity: 3.80 litres

Chassis & suspension

Frame: Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded
Front suspension: 41.3 mm telescopic, triple circuit damping
Rear suspension: Air-adjustable shocks. Mild steel; two-piece drawn and welded section; forged junctions; MIG welded swingarm.
Front wheel travel: 117 mm
Rear wheel travel: 51 mm
Rake (fork angle): 26.0°
Trail: 170 mm

Brakes & wheels

Front brakes: Double disc. 4-piston calipers. Optional ABS.
Front brakes diameter: 300 mm
Rear brakes: Single disc. 4-piston caliper. Optional ABS.
Rear brakes diameter: 300 mm
ABS: Optional
Front tyre: 130/70-BW18
Rear tyre: 180/65-BW16

Other

Color options: Vivid Black, Big Blue Pearl, Ember Red Sunglo, Black Denim, Tequila Sunrise/H-D Orange
Warranty: 24

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2006	2008	2009	2011	2012
Capacity	1442 cc	1573 cc	1584 cc	1584 cc	1688 cc
Dry weight	338 kg	340 kg	355 kg	356 kg	356 kg
Seat height	668 mm	668 mm	690 mm	715 mm	663 mm
Fuel capacity	18.9 L	22.7 L	22.7 L	22.7 L	22.7 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 1 recall may apply

EXTERIOR LIGHTING:BRAKE LIGHTS:SWITCHOct 2011 · 11V506000

HARLEY-DAVIDSON IS RECALLING CERTAIN MODEL YEAR 2009-2012 TOURING, CVO TOURING AND TRIKE VEHICLES MANUFACTURED FROM JUNE 6, 2008, THROUGH SEPTEMBER 16, 2011. SEE THE ABOVE LIST FOR THE MODELS INCLUDED IN THE RECALL. THE REAR BRAKE LIGHT SWITCH MAY BE EXPOSED TO EXCESSIVE HEAT FROM THE EXHAUST SYSTEM.

Risk: THE EXCESSIVE HEAT MAY CAUSE THE SWITCH TO NOT ACTIVATE THE BRAKE LAMP OR ACTIVATE THE BRAKE LAMP WHEN NO BRAKE IS APPLIED AND/OR CAUSE A BRAKE FLUID LEAK AT THE BRAKE LIGHT SWITCH, AFFECTING REAR BRAKE PERFORMANCE. EITHER CONDITION MAY INCREASE THE RISK OF A CRASH.

Remedy: HARLEY-DAVIDSON WILL NOTIFY OWNERS, AND DEALERS WILL A INSTALL A REAR BRAKE LIGHT SWITCH KIT, FREE OF CHARGE. THE SAFETY RECALL IS EXPECTED TO BEGIN DURING OCTOBER 31, 2011. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

These recalls cover some 2012 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.

Source: NHTSA. View all Harley-Davidson recalls →
