2005 Harley-Davidson FLSTCI Heritage Softail Classic

+ Add a photo

Cruisers

2005Harley-Davidson FLSTCI Heritage Softail Classic

29 fields on record

The 2005 Harley-Davidson FLSTCI Heritage Softail Classic is a retro-styled cruiser designed for riders seeking authentic vintage aesthetics with modern reliability. Powered by a 1449cc V-twin engine producing strong mid-range torque, it excels at relaxed highway cruising and commanding presence on city streets. Best known for its classic styling, comfortable riding position, and the Softail's signature hidden rear suspension, it appeals to riders valuing tradition and timeless design.

Capacity: 1449.0 ccm
Engine: V -Twin twin, four-stroke
Gearbox: 5-speed
Dry weight: 322.0 kg
Seat height: 648 mm
Power: 67.0 HP

⇄ Compare with another bike All model years ⚠ Recalls listed (4)

What’s new for the 2005 Harley-Davidson FLSTCI Heritage Softail Classic

vs the 2004

Spec	2004	2005
Engine capacity	1449.00 ccm (88.42 cubic inches)	1449.0 ccm (88.42 cubic inches)
Torque	102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 3500	102.0 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 3500 RPM
Fuel capacity	18.90 litres (4.99 gallons)	18.90 litres (4.99 US gallons)
Front brakes	Single disc	Double disc
Wheelbase	1,630 mm (64.2 inches)	1630 mm (64.2 inches)

Other years 2002 2003 2004 2005

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding45%

Daily riding60%

Touring78%

Two-up75%

Track5%

Best for: Built for relaxed, classic-styled boulevard and highway cruising rather than outright speed or sport handling.
Built for: A traditional, heritage-styled Harley Softail that rewards a laid-back, torque-driven riding style over revvy performance.
Not ideal for: Not a good fit for riders seeking sharp cornering ability, off-road capability, or brisk acceleration.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 648mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2005 Harley-Davidson FLSTCI Heritage Softail Classic, with a cramped knee angle of around 70 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1449.0 ccm
Power: 67.0 HP
Torque: 102.0 Nm (10.4 kgf-m) @ 3500 RPM
Engine type: V -Twin twin, four-stroke
Power/weight ratio: 0.2081 HP/kg
Bore x stroke: 95.3 x 101.6 mm
Compression: 8.8:1
Cooling system: Air
Fuel system: Injection

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate clutch with diaphragm spring in oil bath

Performance

Top speed: 150.0 km/h (93.2 mph)

Dimensions & weight

Wheelbase: 1630 mm
Overall length: 2391 mm
Seat height: 648 mm
Dry weight: 322.0 kg
Fuel capacity: 18.90 litres
Ground clearance: 130 mm

Chassis & suspension

Rake (fork angle): 32.0°

Brakes & wheels

Front brakes: Double disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: MT90-B16
Rear tyre: 150/80-B16

Other

Color options: Vivid black, brilliant silver pearl, black cherry pearl, lava red sunglo, glacier white pearl, rich sunglo blue, two-tone rich sunglo blue and chopper blue pearl, two-tone black cherry pearl and black pearl, two-tone sierra red pearl and brilliant silver

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2002	2003	2004	2005
Capacity	1449.00 ccm (88.42 cubic inches)	1449.00 ccm (88.42 cubic inches)	1449.00 ccm (88.42 cubic inches)	1449.00 ccm (88.42 cubic inches)
Dry weight	335.0 kg (738.5 pounds)	335.0 kg (738.5 pounds)	322.0 kg (709.9 pounds)	322.0 kg (709.9 pounds)
Seat height	644 mm (25.4 inches)	697 mm (27.4 inches)	648 mm (25.5 inches)	648 mm (25.5 inches)
Fuel capacity	18.90 litres (4.99 gallons)	19.70 litres (5.20 gallons)	18.90 litres (4.99 gallons)	18.90 litres (4.99 gallons)
Color options	—	2-tone sterling silver & vivid black, vivid black, gunmetal pearl, luxury rich red pearl, white pearl, luxury blue pearl	Vivid black, brilliant silver, sierra red, luxury teal, luxury blue, glacier white pearl, lava red sunglo, two-tone luxury blue and impact blue, two-tone luxury teal and brilliant silver, two-tone sierra red and brilliant silver, two-tone smokey gold and	Vivid black, brilliant silver pearl, black cherry pearl, lava red sunglo, glacier white pearl, rich sunglo blue, two-tone rich sunglo blue and chopper blue pearl, two-tone black cherry pearl and black pearl, two-tone sierra red pearl and brilliant silver

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 4 open recalls

EQUIPMENT:OTHER:LABELSApr 2005 · 05V151000

CERTAIN SOFTAIL MOTORCYCLES FAIL TO COMPLY WITH THE REQUIREMENTS OF PART 567, 'CERTIFICATION.' THE VIN/CERTIFICATION LABEL CONTAINS INCORRECT TIRE SIZE AND INFLATION PRESSURES FOR THE FRONT WHEEL. THE LABEL STATES THE TIRE SIZE IS MT90B21 AND THE INFLATION PRESSURE AS 30 PSI, WHEREAS THE CORRECT TIRE SIZE IS MT90B16, AND THE CORRECT INFLATION PRESSURE IS 36 PSI.

Risk: THE CERTIFICATION LABEL IS INCORRECT GIVING IMPROPER INFORMATION.

Remedy: HARLEY- DAVIDSON WILL MAIL INSTRUCTIONS ALONG WITH CORRECTED FEDERAL CERTIFICATION LABEL. IF AN OWNER SO DESIRES, A DEALER CAN INSTALL THE LABEL FOR THEM. THE RECALL BEGAN ON JUNE 6, 2005. OWNERS MAY CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

FUEL SYSTEM, GASOLINE:CARBURETOR SYSTEMDec 2004 · 04V607000

CERTAIN MOTORCYCLES MAY HAVE BEEN PRODUCED WITH DEFECTIVE FUEL SHUT-OFF VALVES. THE FUNCTIONALITY OF THE 'ON' POSITION AND THE 'RESERVE' POSITION OF THE VALVE MAY HAVE BEEN REVERSED.

Risk: IF THE BIKE WERE OPERATING WITH THE VALVE IN THE 'ON' POSITION, THE BIKE COULD RUN OUT OF FUEL, THE EXPECTED FUEL RESERVE WILL NOT BE AVAILABLE. THIS COULD LEAD TO THE DRIVER RUNNING OUT OF GAS WITHOUT WARNING, INCREASING THE RISK OF A CRASH.

Remedy: DEALERS WILL INSPECT THE FUEL VALVE AND REPLACE IT, IF NECESSARY. THE RECALL BEGAN FEBRUARY 7, 2005. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-342-4080.

FUEL SYSTEM, GASOLINE:CARBURETOR SYSTEMDec 2004 · 04E094000

CERTAIN FUEL SHUT-OFF VALVES USED AS REPLACEMENT EQUIPMENT, P/NOS 61338-02, 62169-02A, 61338-94D, AND 62169-95C FOR USE ON CERTAIN 2005 CARBURETED SPORTSTERS, DYNA, SOFTAIL, AND TOURING MODEL MOTORCYCLES. THESE VALVES MAY HAVE BEEN PRODUCED WITH THE FUNCTIONALITY OF THE 'ON' POSITION AND THE 'RESERVE' POSITION OF THE VALVE MAY HAVE BEEN REVERSED.

Remedy: DEALERS WILL INSPECT THE FUEL VALVE AND REPLACE IT, IF NECESSARY. THE RECALL BEGAN JANUARY 27, 2005. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-342-4080. IF YOU HAVE HAD OR INSTALLED A REPLACEMENT FUEL SHUT-OFF VALVE IN YOUR MOTORCYCLE, PLEASE TAKE YOUR VEHICLE TO YOUR DEALER TO HAVE THE VALVE INSPECTED FOR PROPER OPERATION AS SOON AS POSSIBLE.

FUEL SYSTEM, GASOLINE:STORAGE:TANK ASSEMBLYSep 2004 · 04V465000

ON CERTAIN MOTORCYCLES, A CONDITION OCCURS THAT COULD ALLOW PRESSURE TO BUILD UP IN THE FUEL TANK. ON FUEL INJECTED VEHICLES, THIS CONDITION COULD CAUSE FUEL TO SPRAY OUT UNEXPECTEDLY WHEN THE FUEL CAP IS REMOVED. ON CARBURETED VEHICLES, EXCESSIVE FUEL COULD BE TRANSFERRED TO THE CARBURETOR, WHICH WOULD EVENTUALLY ALLOW FUEL TO DRIP FROM THE AIR CLEANER.

Risk: THESE SITUATIONS COULD CAUSE SERIOUS PERSONAL INJURY OR CREATE A FIRE HAZARD FOR PERSONS OR PROPERTY ON OR NEAR THE MOTORCYCLE.

Remedy: DEALERS WILL TEST EACH CANISTER FOR BLOCKAGE, THEN REPLACE AS NECESSARY. THE RECALL BEGAN NOVEMBER 4, 2004. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

Source: NHTSA. View all Harley-Davidson recalls →
