Harley-Davidson FLSTFB Fat Boy Lo - 2011 Specifications and Reviews
2011
General information | |
| Category: | Custom / cruiser |
| Year: | 2011 |
| Model: | Harley-Davidson FLSTFB Fat Boy Lo |
Engine and Transmission Specifications | |
| Exhaust system: | Over/under shotgun exhaust with dual mufflers and |
| Driveline: | Primary Drive: Chain, 34/46 ratio. Final Drive: Belt, 32/66 ratio |
| Clutch: | 9-plate, wet |
| Gearbox: | 6-speed |
| Cooling system: | Air |
| Lubrication system: | Pressurized, dry-sump |
| Fuel control: | DOHC |
| Fuel system: | Injection. Electronic Sequential Port Fuel Injection |
| Valves per cylinder: | 2 |
| Bore x stroke: | 95.3 x 111.1 mm (3.8 x 4.4 inches) |
| Compression: | 9.2:1 |
| Torque: | 127.00 Nm (12.9 kgf-m or 93.7 ft.lbs) @ 3000 |
| Engine details: | Twin Cam 96B |
| Engine type: | V2, four-stroke |
| Capacity: | 1584.00 ccm (96.66 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels: | Black, Bullet Hole Disc Cast Aluminum |
| Rear brakes diameter: | 292 mm (11.5 inches) |
| Rear brakes: | Single disc. 2-piston |
| Front brakes diameter: | 292 mm (11.5 inches) |
| Front brakes: | Single disc. 4-piston |
| Rear tyre dimensions: | 200/55-R17 |
| Front tyre dimensions: | 140/75-R17 |
| Rear suspension travel: | 91 mm (3.6 inches) |
| Rear suspension: | Hidden, horizontal-mounted, coil-over |
| Front suspension travel: | 130 mm (5.1 inches) |
| Front suspension: | 41.3mm telescopic, beer can covers |
| Trail: | 147 mm (5.8 inches) |
| Rake (fork angle): | 32.0° |
| Frame type: | Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded. |
Physical measures and capacities | |
| Oil capacity: | 3.10 litres (0.20 quarts) |
| Fuel capacity: | 19.70 litres (5.20 gallons) |
| Wheelbase: | 1,638 mm (64.5 inches) |
| Ground clearance: | 122 mm (4.8 inches) |
| Overall length: | 2,395 mm (94.3 inches) |
| Seat height: | 669 mm (26.3 inches) If adjustable, lowest setting. |
| Dry weight: | 317.5 kg (700.0 pounds) |
Other specs | |
| Carrying capacity: | Front and rear rack |
| Wheelbase: | 1,490 mm (58.7 inches) |
| Overall width: | 1,180 mm (46.5 inches) |
| Overall height: | 1,230 mm (48.4 inches) |
| Power/weight ratio: | 0.1114 HP/kg |
| Rear tyre: | 25/10-12 |
| Front tyre: | 25/8-12 |
| Rear Suspension: | Gas shocks with pre-load adjustment |
| Front Suspension: | Independent double A-arm |
| Transmission type,final drive: | Chain |
| Ignition: | CDI |
| Bore x Stroke: | 96.0 x 82.0 mm (3.8 x 3.2 inches) |
| Compression: | 10.2:1 |
| Torque: | 46.90 Nm (4.8 kgf-m or 34.6 ft.lbs) |
| Power: | 37.55 Horsepower">HP (27.4 Kilowatt">kW)) |
| Capacity: | 594.00 ccm (36.25 cubic inches) |
| Model: | Goes G 625i Max |
| Color options: | Vivid Black, Brilliant Silver Pearl, Black Denim, White Hot Denim |
| Electrical: | Sealed, maintenance-free, 12V battery. |
| Instruments: | Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed ind |
| Starter: | Electric |
