Harley-Davidson FLTRI Road Glide - 2006 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2006
Model:Harley-Davidson FLTRI Road Glide

Engine and Transmission Specifications

Exhaust system:Chrome, cross-over duals
Greenhouse gases:126.9 CO
Fuel consumption:5.47 litres/100 km (18.3 km/l or 43.00 mpg)
Clutch:Multi-plate clutch with diaphragm spring in oil bath
Transmission type,final drive:Belt
Gearbox:5-speed
Fuel system:Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke:95.3 x 101.6 mm (3.8 x 4.0 inches)
Compression:8.9:1
Torque:116.61 Nm (11.9 kgf-m or 86.0 ft.lbs) @ 3500
Power:8.84
Engine type:V2, four-stroke
Capacity:1442.15 ccm (88.00 cubic inches)


Brakes, suspension, Frame and wheels

Rear brakes:Single disc
Front brakes:Double disc
Rear tyre dimensions:MU85-B16
Front tyre dimensions:MT90-B16
Trail:157 mm (6.2 inches)
Rake (fork angle):26.0°

Physical measures and capacities

Fuel capacity:18.92 litres (5.00 gallons)
Wheelbase:1,613 mm (63.5 inches)
Ground clearance:130 mm (5.1 inches)
Overall length:2,380 mm (93.7 inches)
Alternate seat height:749 mm (29.5 inches) If adjustable, highest setting.
Seat height:683 mm (26.9 inches) If adjustable, lowest setting.
Power/weight ratio:0.0267 HP/kg
Weight incl. oil, gas, etc:345.6 kg (762.0 pounds)
Dry weight:331.6 kg (731.0 pounds)

Other specs

Color options:Vivid black, brilliant silver, black cherry, black pearl, chopper blue, fire red pearl, deep cobalt, yellow pearl
