Harley-Davidson FXDF Fat Bob - 2010 Specifications and Reviews

2010
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2010
ModelHarley-Davidson FXDF Fat Bob



Engine and Transmission Specifications

Exhaust systemChrome, 2-1-2 exhaust pipes with
Clutch9-plate, wet
Transmission type,final driveBelt
Gearbox6-speed
Cooling systemAir
Fuel systemInjection. Electronic Sequential Port Fuel Injection
Bore x stroke95.3 x 111.1 mm (3.8 x 4.4 inches)
Compression9.2:1
Torque126.00 Nm (12.8 kgf-m or 92.9 ft.lbs) @ 3500
Engine typeV2, four-stroke
Capacity:1584.00 ccm (96.66 cubic inches)



Brakes, suspension, Frame and wheels

Rear brakes diameter292 mm (11.5 inches)
Rear brakesSingle disc
Front brakes diameter300 mm (11.8 inches)
Front brakesSingle disc
Rear tyre dimensions180/70-B16
Front tyre dimensions130/90-B16
Rear suspension travel79 mm (3.1 inches)
Rear suspensionFully Covered, Coil-over shock
Front suspension travel127 mm (5.0 inches)
Front suspension49mm with polished aluminium fork triple clamp
Trail125 mm (4.9 inches)
Rake (fork angle)29.0°
Frame typeMild steel, tubular frame; rectangular section backbone;

Physical measures and capacities

Oil capacity2.60 litres (0.17 quarts)
Fuel capacity18.80 litres (4.97 gallons)
Wheelbase1,620 mm (63.8 inches)
Ground clearance125 mm (4.9 inches)
Overall length2,330 mm (91.7 inches)
Seat height690 mm (27.2 inches) If adjustable, lowest setting.
Dry weight305.0 kg (672.4 pounds)

Other specs

Color optionsVivid Black, Scarlet Red, Black Denim, Brilliant Silver Denim, Red Hot Sunglo
StarterElectric
