20 June. Wednesday 2018

Harley-Davidson FXD Dyna Super Glide - 2010 Specifications and Reviews

4 stars Average rating: 4 from 1 votes
.

General information

Category:Custom / cruiser
Year:2010
Model:Harley-Davidson FXD Dyna Super Glide


Engine and Transmission Specifications

Exhaust system:Chrome, staggered shorty exhaust with dual mufflers
Clutch:9-plate, wet
Transmission type,final drive:Belt
Gearbox:6-speed
Cooling system:Air
Lubrication system:Pressurized, dry-sump
Fuel system:Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke:95.3 x 111.1 mm (3.8 x 4.4 inches)
Compression:9.2:1
Torque:123.00 Nm (12.5 kgf-m or 90.7 ft.lbs) @ 3125
Engine type:V2, four-stroke
Capacity:1584.00 ccm (96.66 cubic inches)

Brakes, suspension, Frame and wheels

Rear brakes:Single disc
Front brakes:Single disc
Rear suspension travel:79 mm (3.1 inches)
Rear suspension:Coil-over shock
Front suspension travel:127 mm (5.0 inches)
Front suspension:49mm with polished aluminium fork
Rake (fork angle):29.0°
Frame type:Mild steel, tubular frame; rectangular section backbone; stamped,

Physical measures and capacities

Oil capacity:2.60 litres (0.17 quarts)
Fuel capacity:18.80 litres (4.97 gallons)
Wheelbase:1,625 mm (64.0 inches)
Ground clearance:116 mm (4.6 inches)
Overall width:932 mm (36.7 inches)
Overall length:2,357 mm (92.8 inches)
Overall height:1,231 mm (48.5 inches)
Seat height:668 mm (26.3 inches) If adjustable, lowest setting.
Dry weight:295.0 kg (650.4 pounds)

Other specs

Starter:Electric
