Cruisers

2009Harley-Davidson FXSTB Softail Night Train

37 fields on record

The 2009 Harley-Davidson FXSTB Softail Night Train is a classic custom cruiser built for riders seeking authentic V-twin performance and striking styling. Powered by a 1584cc air-cooled engine delivering 117 Nm of torque, it excels at laid-back cruising with commanding presence. Known for its aggressive aesthetics, chrome staggered shorty exhaust, and accessible handling, it appeals to experienced cruiser enthusiasts.

Capacity: 1584.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 6-speed
Dry weight: 303.0 kg
Seat height: 681 mm
Power: 75.0 HP (55.2 kW)

⇄ Compare with another bike All model years

What’s new for the 2009 Harley-Davidson FXSTB Softail Night Train

vs the 2008

Spec	2008	2009
Dry weight	297.6 kg (656.1 pounds)	303.0 kg (668.0 pounds)
Front suspension	—	41.3mm telescopic fork
Rear suspension	—	Hidden, horizontal-mounted, coil-over
Front brakes	Single disc. 4-piston calipers	Single disc
Rear brakes	Single disc. 2-piston torque-free calipers	Single disc

Other years 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding45%

Daily riding50%

Touring40%

Two-up35%

Track10%

Best for: Built for bold, low-slung boulevard cruising and making a visual statement rather than outright performance or long-distance efficiency.
Built for: A dark, muscular Softail with a stripped-down, aggressive Night Train attitude, favoring torque-driven cruising over high-rev thrills.
Not ideal for: Not the right choice for riders seeking agile cornering, off-road capability, or a nimble daily commuter.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 681mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2009 Harley-Davidson FXSTB Softail Night Train, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1584.0 ccm
Power: 75.0 HP (55.2 kW)
Torque: 117.0 Nm (11.9 kgf-m) @ 3200 RPM
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2475 HP/kg (dry)
Bore x stroke: 95.3 x 111.1 mm
Compression: 9.2:1
Cooling system: Air
Fuel system: Injection
Starting: Electric

Transmission

Gearbox: 6-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1700 mm
Overall length: 2410 mm
Seat height: 681 mm
Dry weight: 303.0 kg
Wet weight: 309.3 kg
Fuel capacity: 18.90 litres
Ground clearance: 130 mm

Chassis & suspension

Frame: Mild steel tubular frame; rectangular section backbone;
Front suspension: 41.3mm telescopic fork
Rear suspension: Hidden, horizontal-mounted, coil-over
Front wheel travel: 142 mm
Rear wheel travel: 109 mm
Rake (fork angle): 32.0°
Trail: 127 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: MT90-21
Rear tyre: 200/55-R17

Other

Color options: Vivid Black, Black Pearl, Black Denim, Red Hot Sunglo
Modifications compared to previous model: New low-profile front fender

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1998	2001	2004	2006	2009
Capacity	1338 cc	1450 cc	1450 cc	1450 cc	1584 cc
Dry weight	293 kg	293 kg	293 kg	293 kg	303 kg
Seat height	676 mm	676 mm	676 mm	676 mm	681 mm
Fuel capacity	—	—	—	—	18.9 L
