2003Harley-Davidson FXSTDI Softail Deuce

31 fields on record

The 2003 Harley-Davidson FXSTDI Softail Deuce is a cruiser built for riders seeking classic styling with modern fuel injection reliability. Known for its low-slung design and accessible seat height, it delivers commanding V-twin torque for laid-back highway cruising. Its iconic appearance and straightforward handling make it ideal for traditional cruiser enthusiasts.

Capacity: 1449.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 5-speed
Dry weight: 305.0 kg
Seat height: 696 mm
Power: 67.0 HP (49.3 kW)

⇄ Compare with another bike ＋ Add to garage All model years

What’s new for the 2003 Harley-Davidson FXSTDI Softail Deuce

vs the 2002

Spec	2002	2003
Torque	106.0 Nm (10.8 kgf-m or 78.2 ft.lbs)	105.0 Nm (10.7 kgf-m or 77.4 ft.lbs)
Dry weight	292.7 kg (645.3 pounds)	305.0 kg (672.4 pounds)
Seat height	719 mm (28.3 inches)	696 mm (27.4 inches)
Fuel capacity	18.50 litres (4.89 US gallons)	20.00 litres (5.28 US gallons)
Compression	8.9:1	8.8:1

Other years 2002 2003 2004 2005 2006

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding45%

Daily riding55%

Touring55%

Two-up50%

Track5%

Best for: Built for laid-back boulevard cruising and style-focused riding rather than outright performance or cornering agility.
Built for: A classic American custom cruiser with big V-twin torque, chrome styling, and a relaxed, thumping ride that prioritizes presence over speed.
Not ideal for: Not a good fit for riders wanting sharp handling, off-road capability, or a lightweight, flickable machine for tight cornering.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 696mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2003 Harley-Davidson FXSTDI Softail Deuce, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1449.0 ccm
Power: 67.0 HP (49.3 kW)
Torque: 105.0 Nm (10.7 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2197 HP/kg (dry)
Bore x stroke: 95.3 x 101.6 mm
Compression: 8.8:1
Cooling system: Air
Fuel system: Injection
Valves per cylinder: 2

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate clutch with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1690 mm
Overall length: 2424 mm
Seat height: 696 mm
Dry weight: 305.0 kg
Wet weight: 309.6 kg
Fuel capacity: 20.00 litres
Ground clearance: 140 mm

Chassis & suspension

Rake (fork angle): 32.0°
Trail: 127 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: 90/90-21
Rear tyre: 160/70-17

Other

Color options: 2-tone sterling silver & vivid black, vivid black, gunmetal pearl, luxury rich red pearl, white pearl, luxury blue pearl

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2002	2003	2004	2005	2006
Capacity	1450 cc	1449 cc	1449 cc	1449 cc	1442 cc
Dry weight	293 kg	305 kg	292 kg	292 kg	295 kg
Seat height	719 mm	696 mm	660 mm	660 mm	—
Fuel capacity	18.5 L	20 L	18.9 L	18.5 L	18.5 L
