2005Harley-Davidson FXSTDI Softail Deuce

31 fields on record

The 2005 Harley-Davidson FXSTDI Softail Deuce is a low-slung custom cruiser ideal for riders seeking classic styling with modern fuel injection reliability. Its 1449cc V-twin engine delivers commanding torque, while the iconic Softail frame design combines rigid aesthetics with rear suspension comfort. Best known for its aggressive stance and smooth 5-speed belt drive, this model exemplifies traditional American cruiser character.

Capacity: 1449.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 5-speed
Dry weight: 292.0 kg
Seat height: 660 mm
Power: 67.0 HP (49.3 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (3)

What’s new for the 2005 Harley-Davidson FXSTDI Softail Deuce

vs the 2004

Spec	2004	2005
Fuel capacity	18.90 litres (4.99 US gallons)	18.50 litres (4.89 US gallons)
Front brakes	Single disc	Double disc

Other years 2002 2003 2004 2005 2006

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering30%

City riding45%

Daily riding55%

Touring55%

Two-up50%

Track5%

Best for: Built for laid-back boulevard cruising and style-focused riding rather than outright performance or cornering agility.
Built for: A classic American custom cruiser with big V-twin torque, chrome styling, and a relaxed, thumping ride that prioritizes presence over speed.
Not ideal for: Not a good fit for riders wanting sharp handling, off-road capability, or a lightweight, flickable machine for tight cornering.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 660mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2005 Harley-Davidson FXSTDI Softail Deuce, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1449.0 ccm
Power: 67.0 HP (49.3 kW)
Torque: 101.0 Nm (10.3 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2295 HP/kg (dry)
Bore x stroke: 95.3 x 101.6 mm
Compression: 8.8:1
Cooling system: Air
Fuel system: Injection
Valves per cylinder: 2

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate clutch with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1690 mm
Overall length: 2424 mm
Seat height: 660 mm
Dry weight: 292.0 kg
Wet weight: 309.6 kg
Fuel capacity: 18.50 litres
Ground clearance: 142 mm

Chassis & suspension

Rake (fork angle): 32.0°
Trail: 127 mm

Brakes & wheels

Front brakes: Double disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: 90/90-21
Rear tyre: 160/70-17

Other

Color options: Vivid black, brilliant silver pearl, sierra red pearl, chopper blue pearl, lava red sunglo, glacier white pearl, two-tone rich sunglo blue and chopper blue pearl, two-tone black cherry pearl and black pearl, two-tone smokey gold pearl and vivid black, two

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2002	2003	2004	2005	2006
Capacity	1450 cc	1449 cc	1449 cc	1449 cc	1442 cc
Dry weight	293 kg	305 kg	292 kg	292 kg	295 kg
Seat height	719 mm	696 mm	660 mm	660 mm	—
Fuel capacity	18.5 L	20 L	18.9 L	18.5 L	18.5 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 3 recalls may apply

FUEL SYSTEM, GASOLINE:CARBURETOR SYSTEMDec 2004 · 04V607000

CERTAIN MOTORCYCLES MAY HAVE BEEN PRODUCED WITH DEFECTIVE FUEL SHUT-OFF VALVES. THE FUNCTIONALITY OF THE 'ON' POSITION AND THE 'RESERVE' POSITION OF THE VALVE MAY HAVE BEEN REVERSED.

Risk: IF THE BIKE WERE OPERATING WITH THE VALVE IN THE 'ON' POSITION, THE BIKE COULD RUN OUT OF FUEL, THE EXPECTED FUEL RESERVE WILL NOT BE AVAILABLE. THIS COULD LEAD TO THE DRIVER RUNNING OUT OF GAS WITHOUT WARNING, INCREASING THE RISK OF A CRASH.

Remedy: DEALERS WILL INSPECT THE FUEL VALVE AND REPLACE IT, IF NECESSARY. THE RECALL BEGAN FEBRUARY 7, 2005. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-342-4080.

FUEL SYSTEM, GASOLINE:CARBURETOR SYSTEMDec 2004 · 04E094000

CERTAIN FUEL SHUT-OFF VALVES USED AS REPLACEMENT EQUIPMENT, P/NOS 61338-02, 62169-02A, 61338-94D, AND 62169-95C FOR USE ON CERTAIN 2005 CARBURETED SPORTSTERS, DYNA, SOFTAIL, AND TOURING MODEL MOTORCYCLES. THESE VALVES MAY HAVE BEEN PRODUCED WITH THE FUNCTIONALITY OF THE 'ON' POSITION AND THE 'RESERVE' POSITION OF THE VALVE MAY HAVE BEEN REVERSED.

Remedy: DEALERS WILL INSPECT THE FUEL VALVE AND REPLACE IT, IF NECESSARY. THE RECALL BEGAN JANUARY 27, 2005. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-342-4080. IF YOU HAVE HAD OR INSTALLED A REPLACEMENT FUEL SHUT-OFF VALVE IN YOUR MOTORCYCLE, PLEASE TAKE YOUR VEHICLE TO YOUR DEALER TO HAVE THE VALVE INSPECTED FOR PROPER OPERATION AS SOON AS POSSIBLE.

FUEL SYSTEM, GASOLINE:STORAGE:TANK ASSEMBLYSep 2004 · 04V465000

ON CERTAIN MOTORCYCLES, A CONDITION OCCURS THAT COULD ALLOW PRESSURE TO BUILD UP IN THE FUEL TANK. ON FUEL INJECTED VEHICLES, THIS CONDITION COULD CAUSE FUEL TO SPRAY OUT UNEXPECTEDLY WHEN THE FUEL CAP IS REMOVED. ON CARBURETED VEHICLES, EXCESSIVE FUEL COULD BE TRANSFERRED TO THE CARBURETOR, WHICH WOULD EVENTUALLY ALLOW FUEL TO DRIP FROM THE AIR CLEANER.

Risk: THESE SITUATIONS COULD CAUSE SERIOUS PERSONAL INJURY OR CREATE A FIRE HAZARD FOR PERSONS OR PROPERTY ON OR NEAR THE MOTORCYCLE.

Remedy: DEALERS WILL TEST EACH CANISTER FOR BLOCKAGE, THEN REPLACE AS NECESSARY. THE RECALL BEGAN NOVEMBER 4, 2004. OWNERS SHOULD CONTACT HARLEY-DAVIDSON AT 1-414-343-4056.

These recalls cover some 2005 bikes of this model. Whether one applies to a specific bike, and whether the repair has already been done, depends on its VIN — check your VIN with NHTSA or ask a dealer.
