Harley-Davidson FXSTSSE3 CVO Softail Springer - 2009 Specifications and Reviews

2009
4 stars Average rating: 4 from 1 votes
.

General information

Category:Custom / cruiser
Year:2009
Model:Harley-Davidson FXSTSSE3 CVO Softail Springer

Engine and Transmission Specifications

Clutch:Hydraulically actuated, 9-plate, wet, with high-performance spring
Transmission typefinal drive:Belt
Gearbox:6-speed
Cooling system:Air
Starter:Electric
Fuel system:Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke:101.6 x 111.3 mm (4.0 x 4.4 inches)
Compression:9.2:1
Torque:135.00
Stroke:4
Engine type:V2
Capacity:1800.00 ccm (109.84 cubic inches)


Physical measures and capacities

Wheelbase:1,656 mm (65.2 inches)
Ground clearance:118 mm (4.6 inches)
Overall length:2,327 mm (91.6 inches)
Seat height:648 mm (25.5 inches) If adjustable, lowest setting.
Dry weight:329.0 kg (725.3 pounds)

Harley-Davidson FXSTSSE3 CVO Softail Springer dimensions and frame

Exhaust system:Chrome, slash-down staggered exhaust with
Rear brakes diameter:292 mm (11.5 inches)
Rear brakes:Single disc. 2-piston calipers
Front brakes diameter:292 mm (11.5 inches)
Front brakes:Double disc. 4-piston calipers
Rear tyre dimensions:240/55-R18
Front tyre dimensions:130/70-R18
Rear suspension travel:82 mm (3.2 inches)
Rear suspension:Hidden, horizontal-mounted, coil-over
Front suspension travel:58 mm (2.3 inches)
Front suspension:Leading-link fork
Trail:113 mm (4.4 inches)
Rake (fork angle):32.0°
Frame type:Mild steel, tubular frame; rectangular section backbone;

Speed and acceleration

Color options:Black Diamond with Emerald Ice Flames, Candy Cobalt with Blue Steel Flames, Sunrise Yellow Pearl with Volcanic Fury Flames
Fuel capacity:18.90 litres (4.99 gallons)
