1997Harley-Davidson Softail Custom

17 fields on record

The 1997 Harley-Davidson Softail Custom is a classic cruiser ideal for riders seeking authentic American muscle with timeless style. Known for its distinctive hidden rear suspension and low-slung stance, it delivers robust V-twin performance with 55 horsepower and 97 lb-ft torque. Best suited for cruiser enthusiasts who prioritize comfort and commanding presence over sportiness.

Capacity: 1338.0 ccm
Engine: V-Twin
Gearbox: 5-speed
Dry weight: 276.0 kg
Seat height: 676 mm
Power: 55.0 HP (40.5 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (1)

What’s new for the 1997 Harley-Davidson Softail Custom

vs the 1996

Spec	1996	1997
Power	57.0 HP (41.9 kW)	55.0 HP (40.5 kW)
Top speed	—	155.0 km/h (96.3 mph)
Seat height	737 mm (29.0 inches)	676 mm (26.6 inches)
Front brakes	Dual disc	Single disc

Other years 1996 1997 1998

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering25%

City riding45%

Daily riding50%

Touring45%

Two-up55%

Track5%

Best for: Built for relaxed boulevard cruising and showing off classic custom styling rather than outright performance.
Built for: A laid-back, torque-driven cruiser that rewards a smooth, unhurried riding style over aggressive throttle use.
Not ideal for: Not a good fit for riders seeking sharp cornering ability, high top speed, or any off-road capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 676mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 1997 Harley-Davidson Softail Custom, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1338.0 ccm
Power: 55.0 HP (40.5 kW)
Torque: 97.0 Nm (9.9 kgf-m)
Engine type: V-Twin
Power/weight ratio: 0.1993 HP/kg
Cooling system: Air
Starting: Electric
Valves per cylinder: 2

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt

Performance

Top speed: 155.0 km/h (96.3 mph)

Dimensions & weight

Seat height: 676 mm
Dry weight: 276.0 kg

Brakes & wheels

Front brakes: Single disc
Rear brakes: Single disc

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1996	1997	1998
Capacity	1338 cc	1338 cc	1338 cc
Dry weight	276 kg	276 kg	278 kg
Seat height	737 mm	676 mm	676 mm

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 1 open recall

FUEL SYSTEM, GASOLINE:FUEL INJECTION SYSTEMOct 1996 · 96V204000

THE EFFECTS OF REFORMULATED GASOLINE ALONG WITH CERTAIN USAGE OF THE FUEL SUPPLY VALVE AFFECTS THE SUPPLY OF GASOLINE TO THE CARBURETOR. THIS CONDITION REQUIRES TWO FACTORS: (1) THE USE OF REFORMULATED FUELS CONTAINING MBTE AND (2) STARTING THE MOTORCYCLE WITH THE FUEL VALVE HANDLE IN THE OFF POSITION.

Risk: THIS CONDITION CAN CAUSE THE FUEL FLOW TO BE UNPREDICTABLE THUS CAUSING THE ENGINE TO SHUT DOWN INCREASING THE RISK OF A MOTORCYCLE ACCIDENT.

Remedy: DEALERS THE REPLACE THE DIAPHRAGM IN THE FUEL VALVE.

Source: NHTSA. View all Harley-Davidson recalls →

Rider Reviews

4.8

★★★★★

Rider rating

MotorcycleDB Review

The 1997 Harley-Davidson Softail Custom is a classic and well-loved motorcycle that has stood the test of time. With its sleek design and powerful engine, this bike is a true icon in the world of motorcycles. The Softail Custom offers a smooth and comfortable ride, making it perfect for long journeys or just cruising around town. Its classic look and reliable performance make it a favorite among Harley enthusiasts.

This 1997 Harley-Davidson Softail Custom is a timeless beauty that continues to impress riders with its powerful engine and comfortable ride. The vintage look of this motorcycle is sure to turn heads wherever you go, and its reliable performance will keep you coming back for more. Whether you're a seasoned rider or a new enthusiast, the Softail Custom is a great choice for anyone looking for a classic and dependable motorcycle.
