1996Harley-Davidson Sportster 1200 Custom

37 fields on record

The 1996 Harley-Davidson Sportster 1200 Custom is a classic American cruiser designed for riders seeking authentic style with manageable performance. Its 1199cc V-twin engine delivers accessible torque for relaxed riding, while the low 736mm seat height and 222kg weight make it approachable for various rider sizes. Best known for iconic Harley styling and custom appeal at an entry-level price point.

Capacity: 1199.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 5-speed
Dry weight: 222.0 kg
Seat height: 736 mm
Power: 59.8 HP (44.0 kW)

⇄ Compare with another bike All model years ⚠ Recalls listed (2)

Other years 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering35%

City riding55%

Daily riding60%

Touring45%

Two-up40%

Track10%

Best for: Built for relaxed boulevard cruising, weekend rides, and showing off classic custom styling rather than for speed or sport riding.
Built for: A laid-back, torque-driven cruiser with the classic thump of an air-cooled Evolution V-twin, prioritizing style, sound, and cruising comfort over agility or acceleration.
Not ideal for: Not for riders seeking sharp cornering ability, high-speed touring comfort, or any kind of off-road capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 736mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 1996 Harley-Davidson Sportster 1200 Custom, with a cramped knee angle of around 80 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1199.0 ccm
Power: 59.8 HP (44.0 kW)
Torque: 89.0 Nm (9.1 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2694 HP/kg
Bore x stroke: 88.8 x 96.8 mm
Compression: 9.0:1
Cooling system: Air
Fuel system: Carburettor
Starting: Electric
Valves per cylinder: 2
Lubrication system: Dry sump

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1524 mm
Overall length: 2245 mm
Seat height: 736 mm
Dry weight: 222.0 kg
Wet weight: 245.0 kg
Fuel capacity: 12.50 litres
Ground clearance: 159 mm
Oil capacity: 2.60 litres

Chassis & suspension

Front suspension: Telescopic fork
Rear suspension: Twin shocks
Front wheel travel: 104 mm
Rear wheel travel: 54 mm
Rake (fork angle): 30.0°
Trail: 107 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: 130/90-B16
Rear tyre: 150/80-B16

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	1996	2002	2008	2013	2019
Capacity	1199 cc	1199 cc	1202 cc	1202 cc	1202 cc
Dry weight	222 kg	223 kg	223 kg	245 kg	255 kg
Seat height	736 mm	699 mm	699 mm	699 mm	725 mm
Fuel capacity	12.5 L	12.5 L	12.5 L	12.5 L	17 L

Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.

Safety Recalls

⚠ 2 open recalls

SERVICE BRAKES, HYDRAULICJun 1996 · 96V103000

THE SEAL ON THE REAR MASTER CYLINDER PISTON CAN MOVE OUT OF POSITION.

Risk: THIS CONDITION CAN RESULT IN A LOSS OF REAR BRAKING PERFORMANCE INCREASING THE POTENTIAL FOR A VEHICLE ACCIDENT.

Remedy: DEALERS WILL INSPECT AND, IF NECESSARY, REPLACE THE REAR BRAKE MASTER CYLINDER.

VEHICLE SPEED CONTROLOct 1995 · 95E037000

THE AIR CLEANER BAFFLE PLATE CAN DETACH AND LODGE IN THE THROAT OF THE CARBURETOR.

Risk: THIS CONDITION CAN IMPEDE THE ABILITY OF THE THROTTLEPLATE TO RETURN TO THE IDLE POSITION INCREASING THE POTENTIAL FOR A VEHICLEACCIDENT OR LOSS OF CONTROL OF THE MOTORCYCLE.

Remedy: DEALERS WILL REPLACE THE AIR CLEANER FILTER ON THE AFFECTED MOTORCYCLES. IF OWNERS HAVE PURCHASED A FILTER AND HAVE NOT INSTALLED IT ON THEIR MOTORCYCLES, THEY CAN RETURN THE FILTER FOR A REPLACEMENT OR A REFUND OF THEIR MONEY.

Source: NHTSA. View all Harley-Davidson recalls →
