Touring Motorcycles
1996Harley-Davidson Ultra Classic Electra Glide
23 fields on record
The 1996 Harley-Davidson Ultra Classic Electra Glide is a premium touring cruiser designed for long-distance riders seeking comfort and classic styling. Its 1338cc V-twin engine delivers smooth, low-end torque ideal for highway cruising, while the heavyweight chassis and comprehensive touring features including dual front disc brakes ensure confident control. Known for its iconic styling and relaxed riding position, it remains a benchmark for American touring motorcycles.
- Capacity
- 1338.0 ccm
- Engine
- V-Twin, four-stroke
- Gearbox
- 5-speed
- Dry weight
- 340.0 kg
- Seat height
- 779 mm
- Power
- 61.2 HP (45.0 kW)
What’s new for the 1996 Harley-Davidson Ultra Classic Electra Glide
vs the 1995| Spec | 1995 | 1996 |
|---|---|---|
| Power | 63.0 HP (46.3 kW) | 61.2 HP (45.0 kW) |
| Torque | — | 102.0 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 3000 RPM |
| Dry weight | — | 340.0 kg (749.6 pounds) |
| Wet weight | — | 347.0 kg (765.0 pounds) |
| Seat height | — | 779 mm (30.7 inches) |
| Fuel capacity | — | 18.90 litres (4.99 US gallons) |
| Gearbox | — | 5-speed |
| Front brakes | — | Dual disc |
| Rear brakes | — | Single disc |
| Cooling | — | Air |
| Compression | — | 8.5:1 |
How it rides
Editorial estimate from the spec sheet - not lab tested- Best for
- Built for effortless long-distance highway touring with a passenger and luggage rather than for outright speed or sporty handling.
- Built for
- A classic American cruiser-tourer with relaxed torque-driven power delivery, deep V-twin character, and a plush, upright riding position designed for all-day comfort.
- Not ideal for
- Not a good fit for riders seeking sharp cornering agility, off-road capability, or a lightweight, nimble city commuter.
Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.
Will it fit you?
Worked out in your browser - nothing is sent to usEngine
- Capacity
- 1338.0 ccm
- Power
- 61.2 HP (45.0 kW)
- Torque
- 102.0 Nm (10.4 kgf-m) @ 3000 RPM
- Engine type
- V-Twin, four-stroke
- Power/weight ratio
- 0.1800 HP/kg (dry)
- Bore x stroke
- 88.8 x 108.0 mm
- Compression
- 8.5:1
- Cooling system
- Air
- Starting
- Electric
- Valves per cylinder
- 2
Transmission
- Gearbox
- 5-speed
- Transmission type
- Manual
- Final drive
- Belt
- Clutch
- Multi-plate with diaphragm spring in oil bath
Dimensions & weight
- Seat height
- 779 mm
- Dry weight
- 340.0 kg
- Wet weight
- 347.0 kg
- Fuel capacity
- 18.90 litres
Brakes & wheels
- Front brakes
- Dual disc
- Rear brakes
- Single disc
- Front tyre
- MT90-16T
- Rear tyre
- MT90-16T
Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.
What changed, year to year
Differences highlighted| Specification | 1988 | 1993 | 1996 | 1999 | 2013 |
|---|---|---|---|---|---|
| Capacity | 1338 cc | 1338 cc | 1338 cc | 1450 cc | 1688 cc |
| Dry weight | — | — | 340 kg | 350 kg | 400 kg |
| Seat height | — | — | 779 mm | 692 mm | 693 mm |
| Fuel capacity | — | — | 18.9 L | 18.9 L | 22.7 L |
Illustrative - generated automatically by diffing the year records already on file, not a manufacturer-published changelog.
Rider Reviews
Common questions
What is the engine size of the Harley-Davidson Ultra Classic Electra Glide?
The 1996 Harley-Davidson Ultra Classic Electra Glide has a Capacity of 1338.0 ccm (81.65 cubic inches).
What engine power does the Harley-Davidson Ultra Classic Electra Glide have?
The 1996 Harley-Davidson Ultra Classic Electra Glide has a Power of 61.2 HP (45.0 kW).
How many gears does the Harley-Davidson Ultra Classic Electra Glide have?
The 1996 Harley-Davidson Ultra Classic Electra Glide has a Gearbox of 5-speed.
What is the torque of the Harley-Davidson Ultra Classic Electra Glide?
The 1996 Harley-Davidson Ultra Classic Electra Glide has a Torque of 102.0 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 3000 RPM.
How much does the Harley-Davidson Ultra Classic Electra Glide weigh?
The 1996 Harley-Davidson Ultra Classic Electra Glide has a Dry weight of 340.0 kg (749.6 pounds).
