Harley-Davidson Ultra Limited Low - 2018 Specifications and Reviews
General information | |
| Category: | Touring |
| Year: | 2018 |
| Model: | Harley-Davidson Ultra Limited Low |
Engine and Transmission Specifications | |
| Exhaust system: | Chrome, 2-1-2 dual exhaust with tapered mufflers |
| Greenhouse gases: | 136.9 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption: | 5.90 litres/100 km (16.9 km/l or 39.87 mpg) |
| Driveline: | Chain, 34/46 ratio primary drive |
| Clutch: | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive: | Belt |
| Gearbox: | 6-speed |
| Cooling system: | Oil & air |
| Lubrication system: | Dry sump |
| Fuel control: | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system: | Injection. Electronic Sequential Port Fuel Injection |
| Bore x Stroke: | 100.0 x 111.3 mm (3.9 x 4.4 inches) |
| Compression: | 10.0:1 |
| Torque: | 152.00 Nm (15.5 kgf-m or 112.1 ft.lbs) @ 3250 Revolutions">RPM |
| Power: | 90.00 Horsepower">HP (65.7 Kilowatt">kW)) @ 5450 Revolutions">RPM |
| Engine details: | Twin-Cooled™ Milwaukee-Eight™ 107 |
| Engine type: | V2, four-stroke |
Brakes, suspension, Frame and wheels | |
| Wheels: | Contrast Chrome Impeller Cast Aluminum |
| Rear brakes: | Single disc. ABS. 4-piston |
| Front brakes: | Double disc. ABS. 4-piston |
| Rear tyre: | 180/65-B16 |
| Front tyre: | 130/80-B17 |
| Rear Suspension: | Twin shocks |
| Front Suspension: | Telescopic fork |
| Trail: | 170 mm (6.7 inches) |
| Rake (fork angle): | 26.0° |
Physical measures and capacities | |
| Oil capacity: | 4.70 litres (0.31 quarts) |
| Fuel capacity: | 22.71 litres (6.00 gallons) |
| Wheelbase: | 1,625 mm (64.0 inches) |
| Ground clearance: | 115 mm (4.5 inches) |
| Overall length: | 2,600 mm (102.4 inches) |
| Seat height: | 675 mm (26.6 inches) If adjustable, lowest setting. |
| Power/weight ratio: | 0.2273 HP/kg |
| Weight incl. oil, gas, etc: | 412.0 kg (908.3 pounds) |
| Dry weight: | 396.0 kg (873.0 pounds) |
Other specs | |
| Comments: | Windshield. Infotainment. USB. Bluetooth. |
| Carrying capacity: | Saddle bags, top box |
| Light: | High beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system, 6-speed, low fuel warning, ABS |
| Instruments: | Large speedometer and tachometer with wide numbers; large fuel and volt gauges with wide numbers; display features odometer, trip A, trip B, range to empty, and gear indicator; and larger telltale indicators |
| Starter: | Electric |
| Color options: | Vivid Black, Twisted Cherry, Silver Fortune/Black Tempest, Silver Fortune/Sumatra Brown, Wicked Red/Twisted Cherry, Industrial Gray Denim/Black Denim |
