Harley-Davidson VRSCAW V-Rod - 2010 Specifications and Reviews

2010

2009

2008

Harley-Davidson VRSCAW V-Rod 2010 14902 Thumb

General information
Category:	Custom / cruiser
Year:	2010
Model:	Harley-Davidson VRSCAW V-Rod
Engine and Transmission Specifications
Exhaust system:	Chrome, slash-cut exhaust with dual mufflers
Clutch:	9-plate, wet, A and S (Assist and Slip)
Transmission type,final drive:	Belt
Gearbox:	5-speed
Cooling system:	Liquid
Fuel control:	DOHC
Fuel system:	Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Valves per cylinder:	4
Bore x stroke:	105.0 x 72.0 mm (4.1 x 2.8 inches)
Compression:	11.5:1
Torque:	115.00 Nm (11.7 kgf-m or 84.8 ft.lbs) @ 7000
Engine type:	V2, four-stroke
Capacity:	1250.00 ccm (76.28 cubic inches)

Brakes, suspension, Frame and wheels
Rear brakes diameter:	300 mm (11.8 inches)
Rear brakes:	Single disc. 4-piston
Front brakes diameter:	300 mm (11.8 inches)
Front brakes:	Double disc. 4-piston
Rear tyre dimensions:	240/40-R18
Front tyre dimensions:	120/70-ZR19
Rear suspension travel:	102 mm (4.0 inches)
Rear suspension:	Preload adjustable
Front suspension travel:	102 mm (4.0 inches)
Front suspension:	Wide, 49mm custom fork
Trail:	114 mm (4.5 inches)
Rake (fork angle):	34.0°
Frame type:	Steel perimeter upper frame with hydroformed main rails; and bolt-on lower frame rails, MIG welded

Physical measures and capacities
Oil capacity:	4.40 litres (0.29 quarts)
Fuel capacity:	18.90 litres (4.99 gallons)
Wheelbase:	1,715 mm (67.5 inches)
Ground clearance:	160 mm (6.3 inches)
Overall length:	2,455 mm (96.7 inches)
Seat height:	705 mm (27.8 inches) If adjustable, lowest setting.
Dry weight:	292.0 kg (643.7 pounds)
Other specs
Color options:	Vivid Black, Brilliant Silver Pearl, Black Ice Pearl, Red Hot Sunglo, Flame Blue Pearl/Brilliant Silver Pearl
Starter:	Electric
