Harley-Davidson XL 1200L Sportster 1200 Low - 2006 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes

General information

Category:Custom / cruiser
Model:Harley-Davidson XL 1200L Sportster 1200 Low

Engine and Transmission Specifications

Clutch:Wet multi-plate
Transmission typefinal drive:Belt
Cooling system:Air
Valves per cylinder:2
Fuel system:Carburettor
Bore x stroke:88.9 x 96.8 mm (3.5 x 3.8 inches)
Engine type:V2
Capacity:1199.61 ccm (73.20 cubic inches)

Physical measures and capacities

Wheelbase:1,524 mm (60.0 inches)
Ground clearance:112 mm (4.4 inches)
Overall length:2,294 mm (90.3 inches)
Alternate seat height:711 mm (28.0 inches) If adjustable, highest setting.
Seat height:667 mm (26.3 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:260.8 kg (575.0 pounds)
Dry weight:251.3 kg (554.0 pounds)

Harley-Davidson XL 1200L Sportster 1200 Low dimensions and frame

Exhaust system:Chrome, staggered shorty duals
Rear brakes:Single disc
Front brakes:Double disc
Rear tyre dimensions:150/80-B16
Front tyre dimensions:100/90-19
Trail:117 mm (4.6 inches)
Rake (fork angle):29.6°

Speed and acceleration

Color options:Vivid black, brilliant silver, deep cobalt, glacier white pearl, brandy wine sunglo, two-tone black cherry and black pearl, two-tone glacier white pearl and vivid black, two-tone fire red and vivid black
Fuel capacity:17.03 litres (4.50 gallons)
