2010Harley-Davidson XL 1200L Sportster 1200 Low

40 fields on record

The 2010 Harley-Davidson XL 1200L Sportster 1200 Low is a classic custom cruiser built for riders seeking an accessible, low-slung platform with authentic V-twin character. Its 1202cc air-cooled engine delivers smooth torque through a five-speed transmission, while the low seat height and manageable power make it ideal for both experienced riders and those new to larger motorcycles. Known for its iconic styling, aggressive stance, and chrome details, this Sportster excels as a customizable entry point to the Harley brand.

Capacity: 1202.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 5-speed
Dry weight: 251.0 kg
Seat height: 668 mm
Power: 68.0 HP (50.0 kW)

⇄ Compare with another bike All model years

What’s new for the 2010 Harley-Davidson XL 1200L Sportster 1200 Low

vs the 2009

Spec	2009	2010
Torque	98.0 Nm (10.0 kgf-m or 72.3 ft.lbs)	98.0 Nm (10.0 kgf-m or 72.3 ft.lbs) @ 3200 RPM
Fuel capacity	17.00 litres (4.49 US gallons)	12.50 litres (3.30 US gallons)
Front suspension	39 mm fork	39mm
Rear suspension	Coil-over; preload dual-adjustable	Coil-over shocks, preload dual adjustment
Front brakes	Single disc. 2-piston calipers	Single disc. Dual piston
Wheelbase	1515 mm (59.6 inches)	1510 mm (59.4 inches)

Other years 2006 2007 2009 2010 2011

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering35%

City riding60%

Daily riding60%

Touring40%

Two-up40%

Track10%

Best for: Built for relaxed cruising, boulevard riding, and short-to-medium trips rather than outright speed or long-distance touring.
Built for: A classic torque-driven V-twin cruiser that delivers laid-back, thumping power with strong low-end pull rather than high-rev excitement.
Not ideal for: Not a good fit for riders seeking sharp cornering agility, off-road capability, or serious high-speed touring performance.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 668mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2010 Harley-Davidson XL 1200L Sportster 1200 Low, with a cramped knee angle of around 70 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 1202.0 ccm
Power: 68.0 HP (50.0 kW)
Torque: 98.0 Nm (10.0 kgf-m) @ 3200 RPM
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2709 HP/kg
Bore x stroke: 88.9 x 96.8 mm
Compression: 9.7:1
Cooling system: Air
Fuel system: Injection
Starting: Electric
Valves per cylinder: 2
Lubrication system: Dry-sump

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt

Dimensions & weight

Wheelbase: 1510 mm
Overall length: 2263 mm
Overall width: 894 mm
Overall height: 1189 mm
Seat height: 668 mm
Dry weight: 251.0 kg
Wet weight: 263.5 kg
Fuel capacity: 12.50 litres
Ground clearance: 112 mm
Oil capacity: 2.80 litres

Chassis & suspension

Frame: Mild steel tubular frame; circular sections; cast junctions
Front suspension: 39mm
Rear suspension: Coil-over shocks, preload dual adjustment
Front wheel travel: 92 mm
Rear wheel travel: 92 mm
Rake (fork angle): 30.0°
Trail: 117 mm

Brakes & wheels

Front brakes: Single disc. Dual piston
Front brakes diameter: 292 mm
Rear brakes: Single disc. Single piston
Rear brakes diameter: 292 mm
Front tyre: 100/90-19
Rear tyre: 150/80-B16

Other

Color options: Vivid Black, Flame Blue Pearl, Red Hot Sunglo, Scarlet Red/Vivid Black

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2006	2007	2009	2010	2011
Capacity	1199.61 ccm (73.20 cubic inches)	1199.61 ccm (73.20 cubic inches)	1202.00 ccm (73.35 cubic inches)	1202.00 ccm (73.35 cubic inches)	1201.25 ccm (73.30 cubic inches)
Dry weight	251.3 kg (554.0 pounds)	251.3 kg (554.0 pounds)	251.0 kg (553.4 pounds)	251.0 kg (553.4 pounds)	252.7 kg (557.0 pounds)
Seat height	667 mm (26.3 inches)	667 mm (26.3 inches)	668 mm (26.3 inches)	668 mm (26.3 inches)	668 mm (26.3 inches)
Fuel capacity	17.03 litres (4.50 gallons)	17.03 litres (4.50 gallons)	17.00 litres (4.49 gallons)	12.50 litres (3.30 gallons)	17.03 litres (4.50 gallons)
Color options	Vivid black, brilliant silver, deep cobalt, glacier white pearl, brandy wine sunglo, two-tone black cherry and black pearl, two-tone glacier white pearl and vivid black, two-tone fire red and vivid black	Vivid black, brilliant silver, deep cobalt, glacier white pearl, brandy wine sunglo, two-tone black cherry and black pearl, two-tone glacier white pearl and vivid black, two-tone fire red and vivid black	Vivid Black, Dark Blue Pearl, Flame Blue Pearl, Red Hot Sunglo, White Gold Pearl and Pewter Pearl.	Vivid Black, Flame Blue Pearl, Red Hot Sunglo, Scarlet Red/Vivid Black	Vivid Black, Cool Blue Pearl, Merlot Sunglo
