Harley-Davidson XL 1200X Sportster Forty-Eight - 2010 Specifications and Reviews

2010

General information
Category:	Custom / cruiser
Year:	2010
Model:	Harley-Davidson XL 1200X Sportster Forty-Eight
Engine and Transmission Specifications
Exhaust system:	Chrome, shorty dual exhaust with slash-cut mufflers
Greenhouse gases:	129.9 CO
Fuel consumption:	5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Clutch:	Multi-plate, wet
Transmission type,final drive:	Belt
Gearbox:	5-speed
Cooling system:	Air
Lubrication system:	Dry sump
Fuel system:	Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x stroke:	88.9 x 96.8 mm (3.5 x 3.8 inches)
Compression:	9.7:1
Torque:	107.00 Nm (10.9 kgf-m or 78.9 ft.lbs) @ 4000
Engine type:	V2, four-stroke
Capacity:	1200.00 ccm (73.22 cubic inches)

Brakes, suspension, Frame and wheels
Rear brakes diameter:	292 mm (11.5 inches)
Rear brakes:	Single disc. Single piston
Front brakes diameter:	292 mm (11.5 inches)
Front brakes:	Single disc. Dual piston
Rear tyre dimensions:	150/80-B16
Front tyre dimensions:	MT90-B16
Rear suspension travel:	41 mm (1.6 inches)
Rear suspension:	Coil-over, preload dual adjustments
Front suspension travel:	92 mm (3.6 inches)
Front suspension:	39mm
Trail:	119 mm (4.7 inches)
Rake (fork angle):	29.9°

Physical measures and capacities
Oil capacity:	2.60 litres (0.17 quarts)
Fuel capacity:	8.00 litres (2.11 gallons)
Wheelbase:	1,520 mm (59.8 inches)
Ground clearance:	99 mm (3.9 inches)
Overall width:	831 mm (32.7 inches)
Overall length:	2,250 mm (88.6 inches)
Overall height:	1,067 mm (42.0 inches)
Seat height:	680 mm (26.8 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:	257.0 kg (566.6 pounds)
Dry weight:	247.0 kg (544.5 pounds)
Other specs
Color options:	Vivid Black, Brilliant Silver, Mirage Orange
Starter:	Electric
