What category is the 2004 Harley-Davidson XL 1200 R Sportster Roadster?

The 2004 Harley-Davidson XL 1200 R Sportster Roadster has a Category of Custom / cruiser.

What is the engine size of the 2004 Harley-Davidson XL 1200 R Sportster Roadster?

The 2004 Harley-Davidson XL 1200 R Sportster Roadster has a Capacity: of 1202.00 ccm (73.35 cubic inches).

What type of engine does the 2004 Harley-Davidson XL 1200 R Sportster Roadster have?

The 2004 Harley-Davidson XL 1200 R Sportster Roadster has a Engine type of V2.

What is the torque of the 2004 Harley-Davidson XL 1200 R Sportster Roadster?

The 2004 Harley-Davidson XL 1200 R Sportster Roadster has a Torque of 93.00.

Is the 2004 Harley-Davidson XL 1200 R Sportster Roadster air cooled or liquid cooled?

The 2004 Harley-Davidson XL 1200 R Sportster Roadster has a Cooling system of Air.

How many gears does the 2004 Harley-Davidson XL 1200 R Sportster Roadster have?

The 2004 Harley-Davidson XL 1200 R Sportster Roadster has a Gearbox of 5-speed.

What is the seat height of the 2004 Harley-Davidson XL 1200 R Sportster Roadster?

The 2004 Harley-Davidson XL 1200 R Sportster Roadster has a Seat height of 713 mm (28.1 inches) If adjustable, lowest setting..

Harley-Davidson XL 1200 R Sportster Roadster - 2004 Specifications and Reviews

Name: 2004 Harley-Davidson XL 1200 R Sportster Roadster
Brand: Harley-Davidson

The 2004 Harley-Davidson XL 1200 R Sportster Roadster is a nimble, aggressive cruiser designed for riders seeking classic styling with contemporary performance. Its lightweight 1202cc V-twin engine delivers responsive torque, making it ideal for urban commuting and spirited cornering. Known for accessibility and customization potential, this model appeals to both experienced enthusiasts and newer riders entering the Harley lifestyle.

⇄ Compare against another bike 📅 All Years

2004

❮❯

Harley-Davidson XL 1200 R Sportster Roadster 2004 8220 Thumb

Add/Upload pictures for this motorcycle

General information
Category	Custom / cruiser
Year	2004
Model	Harley-Davidson XL 1200 R Sportster Roadster

Engine and Transmission Specifications
Transmission typefinal drive	Belt
Gearbox	5-speed
Cooling system	Air
Valves per cylinder	2
Fuel system	Carburettor
Bore x stroke	88.8 x 96.8 mm (3.5 x 3.8 inches)
Compression	10.0:1
Torque	93.00
Stroke	4
Engine type	V2
Capacity:	1202.00 ccm (73.35 cubic inches)
Physical measures and capacities
Wheelbase	1,520 mm (59.8 inches)
Ground clearance	112 mm (4.4 inches)
Overall width	713 mm (28.1 inches)
Overall length	2,245 mm (88.4 inches)
Seat height	713 mm (28.1 inches) If adjustable, lowest setting.
Dry weight	251.0 kg (553.4 pounds)
Harley-Davidson XL 1200 R Sportster Roadster dimensions and frame
Rear brakes diameter	292 mm (11.5 inches)
Rear brakes	Single disc
Front brakes diameter	292 mm (11.5 inches)
Front brakes	Double disc
Rear tyre dimensions	150/80-16
Front tyre dimensions	100/90-19
Trail	117 mm (4.6 inches)
Rake (fork angle)	29.6°

Speed and acceleration
Color options	Vivid black, brilliant silver, luxury teal, smokey gold, real red, impact blue, lava red sunglo, racing orange
Fuel capacity	12.90 litres (3.41 gallons)
Other specs
Maintenance	Find parts, fluids, filters, maintenance tools and service items on eBay

Performance Profile & Rider Fit

5.8s

0-60 mph (est.)

Best For

Track15%

City55%

Cornering45%

Daily Riding55%

Touring40%

Passenger35%

Rider Profile

Best For	Suits riders with at least some basic experience who are comfortable managing a heavy, torque-driven V-twin at low speeds.
Purpose	Built for relaxed street cruising and boulevard riding with a slightly sportier, roadster-style stance than a typical Sportster.
Rider Fit	The low seat height makes it approachable for shorter riders, though the substantial dry weight demands confident low-speed handling.
Character	A classic air-cooled Harley V-twin character with strong low-end torque, unmistakable exhaust note, and a raw, mechanical feel.
Not Ideal For	Not a good fit for riders seeking high-speed sport performance, off-road capability, or long-distance touring comfort.

Character map is an editorial estimate based on this bike's specifications, not a lab-tested measurement.

Rider Fit Visualizer

Your height

Inseam (optional)

Units

Calculated in your browser only - your height/inseam are never sent to our servers.

Feet:

At 713mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2004 Harley-Davidson XL 1200 R Sportster Roadster, with a cramped knee angle of around 75 degrees and an upright riding position.

Data quality: measured. Assumes about 30mm of suspension sag once seated (a typical street-bike rule of thumb - stiffer or softer suspension will vary). This is an approximation from category-typical geometry and generic body proportions, not a measurement of this specific bike or you - sit on it before you buy.

Find bikes that fit your height →
