Cruisers

2003Harley-Davidson XL 53C Sportster Custom 53

18 fields on record

The 2003 Harley-Davidson XL 53C Sportster Custom 53 is an air-cooled V-twin cruiser designed for riders seeking authentic American motorcycle character with manageable power. Its 883cc engine delivers accessible torque perfect for both newcomers and experienced riders preferring a lighter, nimble platform. Known for its classic custom styling and low seat height, this Sportster excels as an ideal entry-level Harley or reliable urban commuter.

Capacity: 883.0 ccm
Engine: V -Twin twin, four-stroke
Gearbox: Not on record
Know it? Add it →
Dry weight: 245.0 kg
Seat height: 700 mm
Power: 56.6 HP

⇄ Compare with another bike All model years

What’s new for the 2003 Harley-Davidson XL 53C Sportster Custom 53

vs the 2002

Spec	2002	2003
Engine capacity	883.00 ccm (53.88 cubic inches)	883.0 ccm (53.88 cubic inches)
Torque	67.00	67.0 Nm (6.8 kgf-m or 49.4 ft.lbs)
Fuel capacity	12.50 litres (3.30 gallons)	12.50 litres (3.30 US gallons)
Front brakes	Single disc	not listed
Rear brakes	Single disc	not listed
Wheelbase	1,510 mm (59.4 inches)	1510 mm (59.4 inches)

Other years 2002 2003

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail5%

Cornering35%

City riding55%

Daily riding55%

Touring35%

Two-up30%

Track10%

Best for: Built for relaxed boulevard cruising, weekend rides, and showing off classic custom styling rather than outright performance.
Built for: A laid-back, torque-driven cruiser with classic Harley V-twin thump, styled for looks and cruising presence rather than speed.
Not ideal for: Not suited for riders seeking sport-bike handling, long-distance touring comfort, or any off-road capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 700mm, a rider of 175cm with a 79cm (estimated) inseam will reach the ground with both feet flat on the 2003 Harley-Davidson XL 53C Sportster Custom 53, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 883.0 ccm
Power: 56.6 HP
Torque: 67.0 Nm (6.8 kgf-m)
Engine type: V -Twin twin, four-stroke
Power/weight ratio: 0.2310 HP/kg
Bore x stroke: 76.2 x 96.8 mm
Compression: 9.0:1
Cooling system: Air
Fuel system: Carburettor

Transmission

Final drive: Belt

Dimensions & weight

Wheelbase: 1510 mm
Overall length: 2245 mm
Seat height: 700 mm
Dry weight: 245.0 kg
Fuel capacity: 12.50 litres
Ground clearance: 159 mm

Other

Color options: 2-tone sterling silver & vivid black, vivid black, gunmetal pearl, luxury rich red pearl, white pearl, luxury blue pearl

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2002	2003
Capacity	883.00 ccm (53.88 cubic inches)	883.00 ccm (53.88 cubic inches)
Dry weight	245.0 kg (540.1 pounds)	245.0 kg (540.1 pounds)
Seat height	700 mm (27.6 inches)	700 mm (27.6 inches)
Fuel capacity	12.50 litres (3.30 gallons)	12.50 litres (3.30 gallons)
Color options	—	2-tone sterling silver & vivid black, vivid black, gunmetal pearl, luxury rich red pearl, white pearl, luxury blue pearl
