2003Harley-Davidson XL 883C Sportster 883 Custom

39 fields on record

The 2003 Harley-Davidson XL 883C Sportster 883 Custom is an entry-level cruiser ideal for new riders and those seeking an accessible, stylish motorcycle. Known for its lightweight 883cc V-twin engine, manageable seat height, and classic custom aesthetic, it delivers straightforward cruising performance with iconic Harley character at an affordable price point.

Capacity: 883.0 ccm
Engine: V-Twin, four-stroke
Gearbox: 5-speed
Dry weight: 222.0 kg
Seat height: 701 mm
Power: 53.0 HP (39.0 kW)

⇄ Compare with another bike All model years

Other years 2003 2004 2005 2006 2007 2008 2009 2010

How it rides

Editorial estimate from the spec sheet - not lab tested

Off-road & trail10%

Cornering35%

City riding60%

Daily riding60%

Touring45%

Two-up40%

Track10%

Best for: Built for relaxed cruising and boulevard style rather than outright performance or long-distance touring.
Built for: A classic air-cooled V-twin cruiser that rewards a laid-back riding style with plenty of torque, sound, and presence over outright speed.
Not ideal for: Not the right choice for riders seeking sharp cornering ability, high-speed touring comfort, or any off-road capability.

Scores are derived from the spec sheet using the same model across every bike, so they compare like for like.

Will it fit you?

Worked out in your browser - nothing is sent to us

Your height

Inseam (optional)

Units

At 701mm, a rider of 68.9" with a 31" (estimated) inseam will reach the ground with both feet flat on the 2003 Harley-Davidson XL 883C Sportster 883 Custom, with a cramped knee angle of around 75 degrees and an upright riding position.

Assumes about 30mm of suspension sag once seated. This is an approximation from category-typical geometry, not a measurement of this bike or of you - sit on one before you buy.

More bikes at 750 mm or under — Short Kings →

Find bikes that fit your height →

Full specifications

Engine

Capacity: 883.0 ccm
Power: 53.0 HP (39.0 kW)
Torque: 66.5 Nm (6.8 kgf-m)
Engine type: V-Twin, four-stroke
Power/weight ratio: 0.2387 HP/kg (dry)
Bore x stroke: 76.2 x 96.8 mm
Compression: 9.0:1
Cooling system: Air
Fuel system: Carburettor
Starting: Electric
Valves per cylinder: 2
Lubrication system: Wet sump

Transmission

Gearbox: 5-speed
Transmission type: Manual
Final drive: Belt
Clutch: Multi-plate clutch with diaphragm spring in oil bath

Dimensions & weight

Wheelbase: 1524 mm
Overall length: 2261 mm
Seat height: 701 mm
Dry weight: 222.0 kg
Wet weight: 262.6 kg
Fuel capacity: 12.50 litres
Ground clearance: 119 mm
Oil capacity: 2.50 litres

Chassis & suspension

Frame: Mild steel tubular frame; circular sections; cast junctions
Front suspension: Fork 39mm
Rear suspension: Coil-over shocks, preload dual adjustments
Front wheel travel: 145 mm
Rear wheel travel: 54 mm
Rake (fork angle): 30.1°
Trail: 119 mm

Brakes & wheels

Front brakes: Single disc
Front brakes diameter: 292 mm
Rear brakes: Single disc
Rear brakes diameter: 292 mm
Front tyre: MH90-21
Rear tyre: 150/80-16

Other

Color options: 2-tone sterling silver & vivid black, vivid black, gunmetal pearl, luxury rich red pearl, white pearl, luxury blue pearl

Compiled from manufacturer documentation and user contributions, corrected on an ongoing basis. Spotted something wrong? Tell us.

What changed, year to year

Differences highlighted

Specification	2003	2005	2007	2008	2010
Capacity	883 cc	883 cc	883 cc	883 cc	883 cc
Dry weight	222 kg	222 kg	253 kg	253 kg	255 kg
Seat height	701 mm	701 mm	673 mm	673 mm	715 mm
Fuel capacity	12.5 L	12.5 L	17 L	17 L	17 L
