Harley-Davidson XL 883 R Sportster - 2002 Specifications and Reviews

2002
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2002
Model:Harley-Davidson XL 883 R Sportster

Engine and Transmission Specifications

Transmission type,final drive:Belt
Cooling system:Air
Fuel system:Carburettor
Bore x stroke:76.2 x 96.8 mm (3.0 x 3.8 inches)
Compression:9.0:1
Torque:68.00 Nm (6.9 kgf-m or 50.2 ft.lbs) @ 4000
Engine type:V2, four-stroke
Capacity:883.00 ccm (53.88 cubic inches)


Brakes, suspension, Frame and wheels

Rear brakes diameter:292 mm (11.5 inches)
Rear brakes:Single disc
Front brakes diameter:292 mm (11.5 inches)
Front brakes:Single disc


Physical measures and capacities

Reserve fuel capacity:1.90 litres (0.50 gallons)
Fuel capacity:12.50 litres (3.30 gallons)
Wheelbase:1,510 mm (59.4 inches)
Ground clearance:154 mm (6.1 inches)
Overall length:2,235 mm (88.0 inches)
Seat height:711 mm (28.0 inches) If adjustable, lowest setting.
Dry weight:245.0 kg (540.1 pounds)
